THERA-Trainer tigo / THERA-Trainer veho - User manual
20
Art. No.: A002-629_Rev 06
Last update: CW19/2018
Installing the grips and arm rest
Press locking bolt 2.
Slide therapy grips/arm rest 3 or grip adapter 4 onto crank 1 up to the stop.
Release locking bolt.
Make sure that locking bolts audibly click into place.
When installing the grip adapter, make sure that lock button of cranks locks
audibly.
Note The grip adapter turns the upper body exerciser into an upper part with safety
handle function.
Connecting the power cable
Use exclusively power plug supplied by the manufacturer.
Open protective lid 2.
Insert plug 3 into port 1.
Connect power plug 4 to socket outlet.
The THERA-Trainer is ready for use.
CAUTION!
Risk of injury due to incorrectly attached therapy grips / armrests!
Slide therapy grips/armrests onto crank axle up to the stop.
Make sure that the locking bolt audibly clicks into place.
NOTE!
Material damage due to incorrect installation!
Make sure that plug is plugged in correctly when connecting cables.
Observe position of plug.
