THERA-Trainer tigo / THERA-Trainer veho - User manual
30
Art. No.: A002-629_Rev 06
Last update: CW19/2018
9.7 Hand/arm fixing
Grip adapter
Note The grip adapter turns the upper body exerciser into an upper part with safety
handle function.
Install grip adapter as follows:
Press locking bolt 3.
Slide grip adapter 2 onto crank 1 up to stop.
Release locking bolt.
Make sure that locking bolt latches.
Make sure that crank locks audibly.
The grip adapter is suitable exclusively for holding.
Therapy grips
Therapy grips:
offer variable grip positions.
are exclusively usable if the user's ability to hold the grips safely is sufficient.
For installing or changing the therapy grips, see Installing the grips and
arm rest.
Have a doctor or therapist adjust the therapy grips individually.
If necessary, use wristband to secure arm on therapy grips.
CAUTION!
Material damage due to incorrect use!
Do not use grip adapter to support body weight.
CAUTION!
Risk of injury due to incorrectly installed grip adapter!
Slide grip adapter onto crank axle up to the stop.
Make sure that the locking bolt audibly clicks into place.
