19 TECHNICAL DATA
THERA-Trainer
Dimensions:
leg exerciser
Upper body exerciser
l x w x h
approx. 58-83 cm x 47.3 cm x 63-119 cm
approx. 75-90 cm x 63.8 cm x 110-125.5 cm
Weight:
leg exerciser
Upper body exerciser
approx. 27-38 kg
approx. 39-45 kg
Crank length leg exerciser:
2-stepped
stepless
75 mm/110 mm
65-115 mm
Crank length upper body exerciser:
short
long
75 mm
110 mm
Number of rotations range –
passive training 1-60 rpm
Number of rotations range –
active training 1-90 rpm
Torque range
leg exerciser
Upper body exerciser
approx. 2-22 Nm
approx. 2-8 Nm
Continuous rating 80 Watts
Power input 130 VA
Power supply 230 V~, 50/60 Hz
115 V~, 50/60 Hz
Fuses 2 x T 1.0 A H 250 V (for power supply 230 V)
2 x T 1.6 A H 250 V (for power supply 115 V)
Medical device class IIa
Protection class II
Degree of protection Type BF
Protection category IP21
Sound emission LpA < 70 dB(A)
Ambient conditions for use 5 °C to 40 °C
15 to 90% Rh
700 to 1060 hPa
Ambient conditions for transport/
delivery
-25 °C to 70 °C
15% to 93% Rh
700 to 1060 hPa
Suitable for users with
Body height
Body weight
120 cm to 200 cm
180 kg (120 kg if using articel no. A001-411)
Materials used steel, stainless steel, plastics (POM, PA6, ABS, PE),
rubber
Operational life:
THERA-Trainer
7years
