Immunity
NOTE: U
T
is the supply AC voltage before the test level is applied.
Directives and manufacturer's declaration – Immunity to electromagnetic disturbance
THERA-Trainer is designed for operation in an electromagnetic environment as described below. The customer
or the user of the THERA-Trainer should make sure that the unit is used in such an environment.
Immunity test EC 60601 test level Level of conformity Directive for electromagnetic
environment
Static discharge
(ESD) according to
IEC 61000-4-2
± 6 kV contact discharge
(indirect)
± 8 kV air discharge
± 6 kV contact discharge
± 8 kV air discharge
Floors should be wooden, concrete
or ceramic tiled. If the floor contains
synthetic materials, the relative air
humidity must be at least 30 %.
Fast transient electrical
disturbances/bursts
according to
IEC 61000-4-4
± 2 kV for supply lines
± 1 kV for input and
output lines
± 2 kV for mains supply
lines
± 1 kV for input and
output lines
The quality of the supply voltage
should correspond to that of a typical
business or hospital environment.
Surges according to
IEC 61000-4-5
± 1 kV differential mode
voltage (symmetrical)
± 2 kV common mode
voltage (asymmetrical)
± 1 kV differential mode
voltage (symmetrical)
± 2 kV common mode
voltage (asymmetrical)
The quality of the supply voltage
should correspond to that of a typical
business or hospital environment.
Voltage dips,
short interruptions
and fluctuations of
the supply voltage
according to
IEC 61000-4-11
< 5% U
T
for 0.5 periods
(> 95% dip)
40% U
T
for 5 periods
(60% dip)
70% U
T
for 25 periods
(30% dip)
< 5% U
T
for 5 s
(> 95% dip)
< 5% U
T
for 0.5 periods
(> 95% dip)
40% U
T
for 5 periods
(60% dip)
70% U
T
for 25 periods
(30% dip)
< 5% U
T
for 5 s
(> 95% dip)
The quality of the supply voltage
should correspond to that of a typical
business or hospital environment.
If the user of the THERA-Trainer
requires continuous functioning in
case of power supply interruptions,
we recommend using a non-inter-
ruptible power system or a battery
to supply the THERA-Trainer.
Magnetic field at supply
frequency (50/60 Hz)
in accordance with
IEC 61000-4-8
3 A/m 3 A/m Magnetic fields at mains frequency
should correspond to the typical
values for business and hospital
environments.
