62
SPECIFICATIONS
REFRIGERATION SYSTEM
Compressor Model:
T-500R, T-600R, T-800R, T-800R SPECTRUM
T-1000R, T-1000R SPECTRUM
T-1200R, T-1200R Intermodal, 1200R SPECTRUM
Thermo King X214
Thermo King X426 LSC5
Thermo King X430 LSC5
Refrigerant Charge:
T-500R
T-600R
T-800R
T-1000R T-1200R, T-1200R Intermodal
T-800R/1000R/1200R SPECTRUM
2.5 kg (5.5 lb) R-404A
3.0 kg (6.0 lb) R-404A
3.0 kg (6.0 lb) R-404A
3.8 kg (8.4 lb) R-404A
Approximately 6.1 kg (13.4 lb) to 7.5 kg (16.5 lb) R-404A
Compressor Oil Charge* 3.0 liters (3.2 quarts) X214
4.1 liters (4.3 quarts) X426, X430
Compressor Oil Type Ester base P/N 203-513 required
High Pressure Cutout Switch: Open
Close
3241 ± 48 kPa (470 ± 7 psig)
2586 ± 262 kPa (375 ± 38 psig)
* When the compressor is removed from the unit, oil level should be noted or the oil removed from the compressor should be measured. This
is to be sure that the same amount of oil can be added before placing the replacement compressor in the unit.
ELECTRICAL CONTROL SYSTEM
Control System Voltage 12.5 Vdc
Battery Charging System 12 volt, 37 amp/ 120 amp (SPECTRUM’S), brush type, Thermo King
alternator
Voltage Regulator Setting 13.95 to 14.4 volts @ 77 F (25 C)
NOTE: Fuse F4 (Bypass resistor for Prestolite Alternator) must be removed for the Thermo King Alternator.
