Thermo King T- series User Manual

46
TSR/TSR-3 ALARM CODES
TSR/TSR-3 ALARM CODES
Note: Not all alarm codes are used with all
applications.
Code Description Operator Help
0 No Alarms Exist
2 Check Evaporator
Coil Sensor
Manually monitor
load temperature.
Report alarm at end
of the day.
3 Check (Control)
Return Air Sensor
Manually monitor
load temperature.
Report alarm at end
of the day.
4 Check (Control)
Discharge Air
Sensor
Manually monitor
load temperature.
Report alarm at end
of the day.
5 Check Ambient
Air Sensor
Report alarm at end
of the day.
6 Check Coolant
Temp Sensor
Report alarm at end
of the day.
7 Check Engine
RPM Sensor
Report alarm at end
of the day.
9 High Evaporator
Temperature
Manually monitor
load temperature.
Report alarm at end
of the day.
10 High Discharge
Pressure
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
11 Unit Controlling
on Alternate
Sensor
Manually monitor
load temperature.
Report alarm at end
of the day.
12 Sensor or Digital
Input Shutdown
The indicated zone is
not longer able to
operate and has
been shut down.
Repair immediately.
13 Sensor Check Manually monitor
load temperature.
Report alarm at end
of the day.
14 Defrost
Terminated by
time.
Report alarm at end
of the day.
15 Check Glow Plugs
or Intake Air
Heater
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
16 Manual start not
completed
Report alarm at end
of the day.
Code Description Operator Help
17 Engine Failed to
Crank
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
18 High Engine
Coolant
Temperature
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
19 Low Engine Oil
Pressure
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
20 Engine Failed to
Start
If unit is shut down
repair immediately.
Otherwise, report
alarm at end of the
day.
21 Cooling Cycle
Check
Manually monitor
load temperature.
Report alarm at end
of the day.
22 Heating Cycle
Check
Manually monitor
load temperature.
Report alarm at end
of the day.
23 Cooling Cycle
Fault
The indicated zone is
not longer able to
operate and has
been shut down.
Code Description Operator Help

Thermo King T- series Specifications

General

Refrigerant	R-404A
Voltage	12V/24V DC
Defrost	Electric or Hot Gas
Model	T-series
Cooling Capacity	Varies by model
Power Source	Diesel Engine or Electric
Temperature Range	-29°C to 24°C
Control System	Microprocessor-based
Fuel Tank Capacity	Varies by model
Dimensions	Varies by model
Weight	Varies by model
