40
© Third Dimension Confidential Document D13-1604-GGUSER-EN-3.4
V7.6
Features
Standards Conforms to 802.11a/b/g/e/i/h/j, drafts 802.11k/r, and single-stream 802.11n standards
Frequency Band 2.4GHz & 5GHz
Security Supports WPA/WPA2 (802.11i)
Quality of Service Supports 802.11e and WMM
Antenna Internal only (InSide WLAN)
Operating Temperature 0-40
o
C (32-104
o
F)
Dimensions (W x D x H) 90 x 135 x 190mm (3.5 x 5.3 x 7.5”)
Networking and Security
Security
WEP64/128, TKIP, AES (CCMP), WPA-EAP-TLS, WPA-PSK, WPA2-EAP-TLS, WPA2
-PSK
Channels
2.4 GHz channels: 1-13
5 GHz channels: 36-140 (U-NII Band 1, 2, 2e)
Wireless LAN
Standard 802.11
Radio Redpine Signals RS9110 + Airoha 8230
RF output power 2.4 GHz
802.11b (DSSS): +17dBm (typ.)
802.11g (OFDM): +15dBm (typ.)
802.11n (OFDM): +15dBm (typ.)
RF output power 5 GHz
802.11a (OFDM): +9dBm (typ.)
802.11n (OFDM): +9dBm (typ.)
Output frequency 2.4 GHz
2.412 - 2.462 GHz, channel 1 - 11 (FCC domain)
2.412 - 2.472 GHz, channel 1 - 13 (ETSI, TELEC domain)
5 MHz channel separation
Output frequency 5 GHz
5.180 - 5.240 GHz, U-NII-1 / Channel 36, 40, 44, 48 (FCC, IC, ETSI domain)
5.260 - 5.320 GHz, U-NII-2 / Channel 52, 56, 60, 64 (FCC, IC, ETSI domain)
5.500 - 5.700 GHz, U-NII-2e / Channel 100, 104, 108,112, 116, 120, 124, 128, 132, 136,
140 (FCC, ETSI domain)
5.500 - 5.700 GHz, U-NII-2e / Channel 100, 104, 108,112, 116, 132, 136, 140 (IC domain)
5.745 - 5.825 GHz, U-NII-3 / Channel 149, 153, 157, 161, 165 (FCC domain)
TPC and DFS slave/client operation on 5.260 - 5.320 GHz, 5.500 - 5.700 GHz
20 MHz channel separation
Data Rates 20 Mbps
Modulation
DSSS (BPSK, QPSK, CCK) for 802.11b
OFDM (BPSK, QPSM, 16QAM, 64QAM) for 802.11 g/n
Transmit Power 20dBm
Receiver Sensitivity -69 dBm to -89dBm across the frequency range
Power Requirements
Supply Voltage 12V dc
Charger Voltage 240V/110V ac
Regulatory Approvals
FCC (US) Yes
IC (Canada) Yes
CE/ETSI (Europe) Yes
C-TICK (Australia) No
Telec (Japan) Yes
