THOMSON MEC 310#GENSET CONTROLLER User Manual

MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 104 THOMSON TECHNOLOGY
6030 Nominal settings 4 (split ph)
No. Setting Min. setting Max. setting Factory
setting
6031 Nominal settings 4 Frequency 48.0Hz 62.0Hz 50.0Hz
6032 Nominal settings 4 Generator power 4kW 20000kW 480kW
6033 Nominal settings 4 Generator current 0A 9000A 787A
6034 Nominal settings 4 Generator volt. 50V 25000V 400V
6035 Nominal settings 4 Nom. RPM 4 0 RPM 4000 RPM 1500 RPM
6040 Transformer generator
No. Setting Min. setting Max. setting Factory
setting
6041 Transformer gen. Primary 50V 25000V 440V
6042 Transformer gen. Secondary 50V 480V 440V
6043 Transformer gen. Current prim. 5A 9000A 1000A
6045 Transformer gen. Current sec. 1A 5A 5A
6070 Gen-set mode
No. Setting Min. setting Max. setting Factory
setting
6071 Gen-set mode Setpoint Island Load take over Island
6080 Language
No. Setting Factory setting
6081 Language English Master Master
6082 Language Selectable* No 1
6083 Language Selectable* No 2
6084 Language Selectable* No 3
*See chapter page 40 regarding language selection
If no voltage transformer is used, the setting 440/440V can be maintained.
Each nominal setting can be selected by parameter 6006, M-
logic or by external
communication.
The voltage set in nominal settings 4 is phase (L1) to phase (L2) values.
The date and time can easily be synchronised with the laptop using the TPS 300
software or changed manual via display.
