Parameter overview
Parameter group 1 (Disp. view settings)
7513 Service mode (RTU/ASCII)
6181 Start prepare 7560 Engine I/F
6183 Start On time Hour adjust. ( “Sync. clock” to PC button)
6184 Start Off time Minutes adjust. ( “Sync. Clock” to PC button)
6211 Cool-down Seconds Adjust.( “Sync. Clock” to PC button)
6212 Extended stop Date adjust ( “Sync. Clock” to PC button)
Parameter group 2 (Disp. view settings)
Month adjust ( “Sync. Clock” to PC button)
1030 Overcurrent 1: Delay + Setpoint Year adjust ( “Sync. Clock" to PC button)
1040 Overcurrent 2: Delay + Setpoint
Parameters only configurable from USW
1150 Overvoltage 1: Delay + Setpoint 1000 Reverse power
1160 Overvoltage 2: Delay + Setpoint 2150 Phase sequence error
1170 Undervoltage 1: Delay + Setpoint 2280 Phase rotation
1180 Undervoltage 2: Delay + Setpoint 2160-2170 GB control
1210 Overfrequency 1: Delay + Setpoint 2770 EIC control
1220 Overfrequency 2: Delay + Setpoint 3000-3050 Digital input term. 10-15
1240 Underfrequency 1: Delay + Setpoint 3490 Emergency stop
1250 Underfrequency 2: Delay + Setpoint
3400…3420
Binary
multi input settings
1450 Overload 1: Delay + Setpoint
4120…4390
mA
input settings
1460 Overload 2: Delay + Setpoint
4310…4470
VDO
multi input settings
Parameter group 3 (Disp. view settings)
4510 Gen. overspeed 1
4220 Fuel 1.1: Delay + Setpoint* 4520 Gen. overspeed 2
4230 Fuel 1.2: Delay + Setpoint* 4580 Stop fail
4620 Fuel 1.3: Delay + Setpoint* 4630 Low water temp.
4600 V-belt: Delay 4950 Battery low 2
4610 Charger gen: Delay 5000...5060 Relay functions
6350 D+: Delay 6001…6005 Nominal settings 1
6550 Fuel pump: Delay* 6006 Enable nom. Settings
6551 Fuel pump 1: Setpoint* 6011…6015 Nominal settings 2
6552 Fuel pump 2: Setpoint* 6021…6025 Nominal settings 3 (1 ph)
* Only shown if multi-input 1 is set to VDO 6031…6035 Nominal settings 4 (2ph)
Always shown parameters in display
6041 Transformer U pri. Gen.
4560 Hz/V failure timer 6042 Transformer U sec. Gen.
4580 Stop fail 6043 Transformer I pri. Gen.
4960 Battery low 1: Delay + Setpoint 6044 Transformer I sec. Gen.
4970 Battery High: Delay + Setpoint 6080 Language
6101 Running time 6101 Running time
6105 kWh reset 6160 Run status
6112 Service timer 1: Hours 6171 Tacho – teeth
6113 Service timer 1: Days
6173 Tacho – run setpoint
6116 Service timer 1: Reset
6191 Start attempts
6122 Service timer 2: Hours
6213 Cool-down temperature
6123 Service timer 2: Days
6214 Cool-down reference
6126 Service timer 2: Reset
6290 Idle mode
6130 Alarm horn 6320 Engine heater ON
