MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 67 THOMSON TECHNOLOGY
M-logic
M-logic functionality is included in the unit and is not an option-dependent function.
M-logic is used to execute different commands at predefined conditions. M-logic is not a PLC but
substitutes one, if only very simple commands are needed.
M-logic is a simple tool based on logic events. One or more input conditions are defined, and at the
activation of those inputs the defined output will occur. A great variety of inputs can be selected,
such as digital inputs, alarm conditions and running conditions. A variety of the outputs can also be
selected, such as relay outputs, change of gen-set modes, alarm LEDs and change of running
modes.
The main purpose of M-logic is to give the operator/designer more flexible possibilities of operating
the generator control system.
The M-logic is part of the TPS 300 software, and as such it can only b
configured in the TPS 300 software and not via the display.
