MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 95 THOMSON TECHNOLOGY
Multi-inputs
Binary inputs with wire break
The text for the inputs for correct display reading can only be done via the TPS 300 software.
3400 Binary input 1 (fuel)
No. Setting Min. setting Max. setting Factory
setting
3401 Binary input 1 Wire break OFF ON OFF
3402 Binary input 1 Delay 0.0 s 100.0 s 5.0 s
3403 Binary input 1 Output A R0 (none) R26 (relay 26) R0 (none)
3404 Binary input 1 Output B R0 (none) R26 (relay 26) R0 (none)
3405 Binary input 1 Enable OFF ON OFF
3406 Binary input 1 Fail class See description of fail classes
3410 Binary input 2 (oil)
No. Setting Min. setting Max. setting Factory
setting
3411 Binary input 2 Wire break OFF ON OFF
3412 Binary input 2 Delay 0.0 s 100.0 s 5.0 s
3413 Binary input 2 Output A R0 (none) R26 (relay 26) R0 (none)
3414 Binary input 2 Output B R0 (none) R26 (relay 26) R0 (none)
3415 Binary input 2 Enable OFF ON OFF
3416 Binary input 2 Fail class See description of fail classes
3420 Binary input 3 (temp.)
No. Setting Min. setting Max. setting Factory
setting
3421 Binary input 3 Wire break OFF ON OFF
3422 Binary input 3 Delay 0.0 s 100.0 s 5.0 s
3423 Binary input 3 Output A R0 (none) R26 (relay 26) R0 (none)
3424 Binary input 3 Output B R0 (none) R26 (relay 26) R0 (none)
3425 Binary input 3 Enable OFF ON OFF
3426 Binary input 3 Fail class See description of fail classes
It is possible to combine VDO inputs with binary inputs and (0)4…20mA inputs in a
mix.
