THOMSON MEC 310#GENSET CONTROLLER User Manual

MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 94 THOMSON TECHNOLOGY
2280 Phase rotation
No. Setting Min. setting Max. setting Factory
setting
2281 Phase rotation Setpoint L1L2L3 L1L3L2 L1L2L3
2282 Phase rotation Password Customer Service Customer
2770 EIC control
3000-3050 Digital input term. 10-15, without wire break
No. Setting Min. setting Max. setting Third
setting
Factory
setting
30X1 Dig. input no. XX Timer 0.0 s 3200.0 s - 10.0 s
30X2 Dig. input no. XX Relay output A R0 (none) R26 (relay 26) - R0 (none)
30X3 Dig. input no. XX Relay output B R0 (none) R26 (relay 26) - R0 (none)
30X4 Dig. input no. XX Enable OFF ON Inhibit OFF
30X5 Dig. input no. XX Fail class See description of fail classes
30X6 Dig. input no. XX NO/NC NO NC - NO
3490 Emergency stop (terminal 19-20)
No. Setting Min. setting Max. setting Factory
setting
3491 Emergency STOP Timer 0.0 s 60.0 s 0.2 s
3492 Emergency STOP Relay output A R0 (none) R26 (relay 26) R0 (none)
3493 Emergency STOP Relay output B R0 (none) R26 (relay 26) R0 (none)
3494 Emergency STOP Enable OFF ON ON
3495 Emergency STOP Fail class See description of fail classes
No. Setting Min. setting Max. setting Factory setting
2771 EIC Control Droop 0.0% 25.0% 0.0%
2772 EIC Control Scania rpm User
1500 rpm
1800 rpm
Low idle
User
2773 EIC Control Cummins gain 0.00 10.00 5.00
The setting of Phase rotation depends of the wiring of Mains L1, L2 and L3.
