MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 76 THOMSON TECHNOLOGY
TPS 300 software connection via modem
TPS 300 software
Press the application settings push-button.
The settings dialog box appears:
Select modem and key in the telephone number of your GSM modem connected to the unit.
When you want to use modem dial-up, the TPS 300 software must also be set to run ASCII 7 bits
data communication:
If a TPS 300 software connection is required, then the SIM
data transfer. Contact your GSM provider for details.
In the above example the modem is selected automatically by the TPS 300
software (internal modem in the PC).
