MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 107 THOMSON TECHNOLOGY
6210 Run/stop (cooling down)
No. Setting Min. setting Max. setting Factory
setting
6211 Run/stop (P1) Cooling down time 0.0 s 999.0 s 240.0 s
6212 Run/stop (P1) Extended STOP 1.0 s 99.0 s 5.0 s
6213 Cool. down temp. Cool down temp. 0°C 302°C 70°C
6214 Reference Input for temp. ref. VDO 3 EIC VDO 3
Hz/V monitoring settings
6220 Hz/V OK
No. Setting Min. setting Max. setting Factory
setting
6221 Hz/V OK
*
Timer 1.0 s 99.0 s 5.0 s
6222 Hz/V OK
*
Voltage 1% 70% 10%
6223 Hz/V OK
*
Frequency 1Hz 20Hz 5Hz
6290 Idle mode
No. Setting Min. setting Max. setting Factory
setting
6291 Idle mode Enable OFF ON OFF
6292 Idle mode Timer 1.0 s 300.0 s 5.0 s
6293 Idle mode Active Man. Man./aut. Aut.
Idle mode can be controlled via a binary input. If this is selected, the idle mode remains for as long
as the input is ON. If a binary input is not used, the idle mode can be selected to be active for
manual or auto or both running modes.
- Both manual and auto: Select Man./Auto
- Manual only: Select Man.
- Auto only: Select Auto
6320 Engine heater on
No. Setting Min. setting Max. setting Factory
setting
6321 External heater on Set point 0 C/F 100 C/F 10 C/F
6330 Engine heater off
No. Setting Min. setting Max. setting Factory
setting
6331 External heater off Set point 0 C/F 100 C/F 20 C/F
The setting ranges refer to nominal setting (nominal voltage +/-
frequency +/- setting Hz).
In order to make the external heater function work, a relay must be designated
to this function in the output settings.
