THOMSON MEC 310#GENSET CONTROLLER User Manual

MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 91 THOMSON TECHNOLOGY
Engine alarm settings (protection)
1000 Reverse power
No. Setting Min.
setting
Max. setting Third
setting
Factory
setting
1001 Reverse power Set point -50.0% 0.0% - -5.0%
1002 Reverse power Timer 0.1 s 100.0 s - 10.0 s
1003 Reverse power Relay output A R0 (none) R26 (relay 26) - R0 none)
1004 Reverse power Relay output B R0 (none) R26 (relay 26) - R0 none)
1005 Reverse power Enable OFF ON Inhibit ON
1006 Reverse power Fail class Warning Shutdown - Trip
1030 Gen Overcurrent 1
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1031 Overcurrent 1 (P2) Set point 50.0% 200.0% - 115.0%
1032 Overcurrent 1 (P2) Timer 0.1 s 3200.0 s - 10.0 s
1033 Overcurrent 1 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1034 Overcurrent 1 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1035 Overcurrent 1 Enable OFF ON Inhibit ON
1036 Overcurrent 1 Fail class Warning Shutdown - Trip
1040 Gen Overcurrent 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1041 Overcurrent 2 (P2) Set point 50.0% 200.0% - 120.0%
1042 Overcurrent 2 (P2) Timer 0.1 s 3200.0 s - 5.0 s
1043 Overcurrent 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1044 Overcurrent 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1045 Overcurrent 2 Enable OFF ON Inhibit ON
1046 Overcurrent 2 Fail class Warning Shutdown - Trip
1150 Gen Overvoltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1151 Overvoltage (P2) Set point 80.0% 150.0% - 115.0%
1152 Overvoltage (P2) Timer 0.1 s 100.0 s - 10.0 s
1153 Overvoltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1154 Overvoltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1155 Overvoltage Enable OFF ON Inhibit ON
1156 Overvoltage Fail class Warning Shutdown - Warning
1160 Gen overvoltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1161 Overvoltage2(P2) Set point 80.0% 120.0% - 117.0%
1162 Overvoltage2(P2) Timer 0.1 s 100.0 s - 10.0 s
1163 Overvoltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1164 Overvoltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1165 Overvoltage2 Enable OFF ON Inhibits ON
1166 Overvoltage2 Fail class Warning Shutdown - Warning
