MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 96 THOMSON TECHNOLOGY
Analogue inputs 0(4)-20mA
The scaling of the 0(4)-20mA inputs for correct display reading can only be done via the TPS 300
software.
4120 0-20 4-20mA 1.1
No. Setting Min. setting Max. setting Factory
setting
4121 0(4)-20mA 1.1 Set point 4mA 20mA 10mA
4122 0(4)-20mA 1.1 Delay 0.0 s 100.0 s 5.0 s
4123 0(4)-20mA 1.1 Output A R0 (none) R26 (relay 26) R0 (none)
4124 0(4)-20mA 1.1 Output B R0 (none) R26 (relay 26) R0 (none)
4125 0(4)-20mA 1.1 Enable OFF ON OFF
4126 0(4)-20mA 1.1 Fail class See description of fail classes
4130 0-20 4-20mA 1.2
No. Setting Min. setting Max. setting Factory
setting
4131 0(4)-20mA 1.2 Set point 4mA 20mA 10mA
4132 0(4)-20mA 1.2 Delay 0.0 s 100.0 s 5.0 s
4133 0(4)-20mA 1.2 Output A R0 (none) R26 (relay 26) R0 (none)
4134 0(4)-20mA 1.2 Output B R0 (none) R26 (relay 26) R0 (none)
4135 0(4)-20mA 1.2 Enable OFF ON OFF
4136 0(4)-20mA 1.2 Fail class See description of fail classes
4250 0-20 4-20mA 2.1
No. Setting Min. setting Max. setting Factory
setting
4251 0(4)-20mA 2.1 Set point 4mA 20mA 10mA
4252 0(4)-20mA 2.1 Delay 0.0 s 100.0 s 5.0 s
4253 0(4)-20mA 2.1 Output A R0 (none) R26 (relay 26) R0 (none)
4254 0(4)-20mA 2.1 Output B R0 (none) R26 (relay 26) R0 (none)
4255 0(4)-20mA 2.1 Enable OFF ON OFF
4256 0(4)-20mA 2.1 Fail class See description of fail classes
4260 0-20 4-20mA 2.2
No. Setting Min. setting Max. setting Factory
setting
4261 0(4)-20mA 2.2 Set point 4mA 20mA 10mA
4262 0(4)-20mA 2.2 Delay 0.0 s 100.0 s 5.0 s
4263 0(4)-20mA 2.2 Output A R0 (none) R26 (relay 26) R0 (none)
4264 0(4)-20mA 2.2 Output B R0 (none) R26 (relay 26) R0 (none)
4265 0(4)-20mA 2.2 Enable OFF ON OFF
4266 0(4)-20mA 2.2 Fail class See description of fail classes
4-20mA inputs have wire break function. Wire break alarm will be active when
current goes below 2,5mA. It’s not possible to disable
