MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 92 THOMSON TECHNOLOGY
1170 Gen undervoltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Undervoltage (P2)
Set point 50.0% 110.0% - 90.0%
1172 Undervoltage (P2)
Timer 0.1 s 100.0 s - 5.0 s
1173 Undervoltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Undervoltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Undervoltage Enable OFF ON Inhibit ON
1176 Undervoltage Fail class Warning Shutdown - Warning
1180 Gen undervoltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Undervoltage2(P2)
Set point 50.0% 110.0% - 85.0%
1172 Undervoltage2(P2)
Timer 0.1 s 100.0 s - 5.0 s
1173 Undervoltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Undervoltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Undervoltage2 Enable OFF ON Inhibits ON
1176 Undervoltage2 Fail class Warning Shutdown - Warning
1210 Gen overfrequency
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1211 Overfrequency (P2)
Set point 80.0% 150.0% - 115.0%
1212 Overfrequency (P2)
Timer 0.1 s 100.0 s - 10.0 s
1213 Overfrequency Relay output A R0 (none) R26 (relay 26) - R0 (none)
1214 Overfrequency Relay output B R0 (none) R26 (relay 26) - R0 (none)
1215 Overfrequency Enable OFF ON Inhibit ON
1216 Overfrequency Fail class Warning Shutdown - Warning
1220 Gen overfrequency 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1221 Overfrequency 2 Set point 80.0% 120.0% - 117.0%
1222 Overfrequency 2 Timer 0.1 s 100.0 s - 10.0 s
1223 Overfrequency 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1224 Overfrequency 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1225 Overfrequency 2 Enable OFF ON Inhibits ON
1226 Overfrequency 2 Fail class Warning Shutdown - Warning
1240 Gen underfrequency
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1241 Underfrequency (P2)
Set point 50.0% 110.0% - 90.0%
1242 Underfrequency (P2)
Timer 0.1 s 100.0 s - 5.0 s
1243 Underfrequency Relay output A
R0 (none) R26 (relay 26) - R0 (none)
1244 Underfrequency Relay output B
R0 (none) R26 (relay 26) - R0 (none)
1245 Underfrequency Enable OFF ON Inhibit ON
1246 Underfrequency Fail class Warning Shutdown - Warning
