THOMSON MEC 310#GENSET CONTROLLER User Manual

MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 93 THOMSON TECHNOLOGY
1250 Gen underfrequency 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1251 Underfrequency 2 (P2) Set point 50.0% 110.0% - 85.0%
1252 Underfrequency 2 (P2) Timer 0.1 s 100.0 s - 5.0 s
1253 Underfrequency 2 Relay output
A
R0 (none) R26 (relay 26) - R0 (none)
1254 Underfrequency 2 Relay output
B
R0 (none) R26 (relay 26) - R0 (none)
1255 Underfrequency 2 Enable OFF ON Inhibits ON
1256 Underfrequency 2 Fail class Warning Shutdown - Warning
1450 Gen overload 1
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1451 Overload 1(P2) Set point 10.0% 200.0% - 100.0%
1452 Overload 1(P2) Timer 0.1 s 3200.0 s - 5.0 s
1453 Overload 1 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1454 Overload 1 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1455 Overload 1 Enable OFF ON Inhibits ON
1456 Overload 1 Fail class Warning Shutdown - Warning
1460 Gen overload 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1461 Overload 2(P2) Set point 10.0% 200.0% - 110.0%
1462 Overload 2(P2) Timer 0.1 s 3200.0 s - 5.0 s
1463 Overload 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1464 Overload 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1465 Overload 2 Enable OFF ON Inhibits ON
1466 Overload 2 Fail class Warning Shutdown - Warning
2150 Phase sequence error
No. Setting Min. setting Max. setting Third
setting
Factory
setting
2152 Phase seq error Timer 0.0 s 10.0 s - 1.0 s
2153 Phase seq error Relay output A R0 (none) R26 (relay 26) - R0 (none)
2154 Phase seq error Relay output B R0 (none) R26 (relay 26) - R0 (none)
2155 Phase seq error Enable OFF ON Inhibit OFF
2156 Phase seq error Fail class Warning Shutdown - Warning
2160 GB open failure
No. Setting Min. setting Max. setting Factory
setting
2161 GB open failure Timer 0.0 s 10.0 s 1.0 s
2170 GB close failure
No. Setting Min. setting Max. setting Factory
setting
2171 GB close failure Timer 0.0 s 10.0 s 1.0 s
