Page #110 background imageLoading...
Page #110 background image
MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 106 THOMSON TECHNOLOGY
The running status detection has two purposes:
1. When the time delay period expires, all the alarms which have Enable selected to ‘Not run
status’ will be activated.
2. An output relay can be selected, if one is available. In that case, the settings output A and
output B must be set according to the desired relay. To avoid an unwanted display alarm,
‘RUN STATUS ALARM’, the function of this relay must be selected to ‘Limit’ function to
avoid the alarm when the engine starts. Notice that both output A and output B must have
the same settings, when the function of the relay is set only as limit switch.
6170 Tacho config.
No. Setting Min. setting Max. setting Factory
setting
6173 Tacho config. Set point 0 RPM 4000 RPM 400 RPM
6171 Tacho config. Number of teeth 0 teeth 500 teeth 0 teeth
6180 Starter
No. Setting Min. setting Max. setting Factory
setting
6181 Starter (P1) Start prepare 0.0 s 600.0 s 5.0 s
6183 Starter (P1) Start ON time 1.0 s 180.0s 5.0 s
6184 Starter (P1) Start OFF time 1.0 s 99.0 s 5.0 s
6190 Start attempts
No. Setting Min. setting Max. setting Factory
setting
6191 Start attempts Attempts 1 10 3
6192 Start attempts Relay output A R0 (none) R26 (relay 26) R0 (none)
6193 Start attempts Relay output B R0 (none) R26 (relay 26) R0 (none)
The settings “start prepare”, “start ON time” and “start OFF time” are the
periods in wh
ich the start relay is activated.
The start prepare output can e.g. be used for prelubricating or preheating
. The
start relay output is for activating the engine starter. The start sequence can be
activated manually by pressing the “START” push-button in Local (hand) mode.
If no output relay has been chosen as starter relay, the start and stop
sequences (cooling down) will be ignored, and the MEC 310 will only operate as
a safety stop device.
The * indicates parameters that can be changed via the push-buttons/display.
The tacho config. set point is used to deactivate the start relay. The number of
teeth is used to configure the tacho input. The tacho input m
ust be configured to
0 teeth when not in use. The tacho input accepts magnetic pick-
up (direct
connection) or NPN/PNP/charger generator W input. Refer to functional
description for information. Note that the frequency range for the tacho input is
10Hz to 10000Hz.
