MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 19 THOMSON TECHNOLOGY
External I/O modules
For wiring details, please refer to ‘Wiring instructions’ in this section.
If External I/O modules is used together with EAP 300, the total terminal
resistance of the EAP 300 and the External I/O controller must be 120Ω
