MEC 310 GENSET CONTROLLER
PM075 REV 2 09/08/20 Page 22 THOMSON TECHNOLOGY
Relay outputs: 3 relays (R21-R23): 30V DC/AC 2A (UL/cUL Listed: 1A
Resistive)
2 relays (MB & GB): 250V AC 30V DC 2A (UL/cUL Listed: Contact
ratings 30V DC/30V AC 2A resistive)
2 relays (R24 & R26): 30V DC/AC 8A (UL/cUL Listed: 6A Resistive)
1 status relay: 24V DC 1A Resistive
Mounting: Panel mounted
Size: 160 x 220mm
EMC/CE: To EN 61000-6-1/2/3/4
SS4631503 (PL4) and IEC 255-3
Material: All plastic materials are self-extinguishing according to UL94
Plug connections: AC voltage inputs:
3.5 mm
2
multi stranded (13 AWG)
Other:
1.5 mm
2
multi stranded (16 AWG)
Tightening torque, min.: AC voltage input: 0.5Nm
Other: 0.5Nm
PC connection: RS232 converter box (option J5)
Approval: CE & UL/cUL listed
Weight: Approx. 0.9 kg (2.0 lbs)
UL/cUL demands: Use 60/75°C copper conductors only
Main disconnect must be provided by installer
Installed in accordance with the NEC (United States) or the CEC
(Canada)
Use listed or R/C (XODW2,8) current transformers
