Chapter 11 Specifications
Measurement
1
Parameter
Range
Repeatability
2
Reproducibility
3
Spherical Fiber Height
±160 nm
5 nm
10 nm
Apex Offset
0-100 µm
2 µm
4 µm
Radius of Curvature
3-50 mm
1%
2%
1
All repeatability and reproducibility data presented are 1 sigma values
2
Repeatability is based on 50 consecutive undisturbed measurements.
3
Reproducibility is based on 50 measurements with connector reinsertion between each measurement.
Interferometer
Dimensions (L x W x H)
13.9” x 8.8” x 5.9”
Light Source
LED (660 nm)
Camera
CCD w/ 5.79 mm x 4.89 mm (1/3 inch) Sensing Area
Measurement Lateral Resolution
1 µm
Magnification
10X Objective
Field of View (H x V)
358 µm x 336 µm
Computer Minimum Requirements
Speed
Pentium IV 1.5 GHz
USB
2.0
Operating System
Microsoft
®
Windows
®
7
RAM
1 GB
