Description Parameter Unit Setting range
Input Mask2
IN33 | IN34 | IN35 | IN36 | IN37 | IN38 | IN39 |
IN40 | IN41 | IN42
Virtual Inputs - VIN
Settings
Profi le
Enable Switch settings profi le
OFF | ON
Settings Profi le
Profi le A | Profi le B
Input Vin (link)
VIN1 | VIN2 | VIN3 | VIN4 | VIN5 | VIN6 | VIN7
| VIN8 | VIN9 | VIN10 | VIN11 | VIN12 | VIN13 |
VIN14 | VIN15 | VIN16 | VIN17 | VIN18 | VIN19
| VIN20 | VIN21 | VIN22 | VIN23 | VIN24 |
VIN25 | VIN26 | VIN27 | VIN28 | VIN29 | VIN30
| VIN31 | VIN32 | NONE
LinkLoss
Enable link loss
OFF | ON
Input Vin (link)
VIN1 | VIN2 | VIN3 | VIN4 | VIN5 | VIN6 | VIN7
| VIN8 | VIN9 | VIN10 | VIN11 | VIN12 | VIN13 |
VIN14 | VIN15 | VIN16 | VIN17 | VIN18 | VIN19
| VIN20 | VIN21 | VIN22 | VIN23 | VIN24 |
VIN25 | VIN26 | VIN27 | VIN28 | VIN29 | VIN30
| VIN31 | VIN32 | NONE
LinkLoss Timer
Value
s 3.0 ... 60.0 step = 0.1
VIN
VIN1-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN1-Function (B)
none
VIN1-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN2-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN2-Function (B)
none
VIN2-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN3-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN3-Function (B)
none
VIN3-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN4-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN4-Function (B)
none
VIN4-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN5-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN5-Function (B)
none
