Thytronic Pro-N NVA100X-D - Page 236

236
NVA100X-D - Manual - 02 - 2016
FUNCTION CHARACTERISTICS
)c(w)
w = H, L
Gnd(w) = Out
w = H, L
Gnd(w) = In
w = H, L
-180
Applied to the w secondary side
of power transformers Yy6, Dd6,
Dz6, Zd6 where the primary side
is the reference side for phase
compensation.
C(w) = 0 -1 0
-1
0 0
0 0 -1
Same as Yy0 adapter CTs with transformation
ratio 1 / 1 on the side w. The connection of the
secondary phase of the CT-adapters to the
relay inputs is L1-L1, L2-L2, L3-L3, with reverse
polarity.
C(w) = -1/3 2/3 -1/3
2/3 -1/3 -1/3
-1/3 -1/3 2/3
Same as Yy0 adapter CTs with transformation ratio 1 /
1 on the side w and connected with the tertiary delta
closed in short-circuit with transformation ratio 1 / 3
that removes the zero-sequence component from the
compensated current for the side w. The connection
of the secondary phase of the CT-adapters to the relay
inputs is L1-L1, L2-L2, L3-L3, with reverse polarity.
-210
Applied to the w secondary side
of power transformers Dy5, Zy5
where the primary side is the
reference side for phase com-
pensation.
C(w) = 1/√3 -1/√3 0
-1/√3 0 1/√3
0 1/√3 -1/√3
Same as Yd7 adapter CTs with transformation
ratio 1 / 3 on the side w. The connection of the
secondary phase of the CT-adapters to the
relay inputs is L1-L1, L2-L2, L3-L3, with the same
polarity.
C(w) = 1/√3 -1/√3 0
-1/√3 0 1/√3
0 1/√3 -1/√3
Same as Yd7 adapter CTs with transformation ratio
1 / 3 on the side w. The connection of the secondary
phase of the CT-adapters to the relay inputs is L1-L1,
L2, L2, L3, L3, with the same polarity.
-240
Applied to the w secondary side
of power transformers Dd4,
Dz4, Zd4 where the primary side
is the reference side for phase
compensation.
C(H) = 1 0 0
0
0 1
0 1 0
Same as Yy0 adapter CTs with transformation
ratio 1 / 1 on the side w. The connection of the
secondary phase of the CT-adapters to the
relay inputs is L3-L1, L1-L2, L2-L3, with the same
polarity.
C(w) = 2/3 -1/3 -1/3
-1/3 -1/3 2/3
-1/3 2/3 -1/3
Same as Yy0 adapter CTs with transformation ratio
1 / 1 on the side we connected with the tertiary delta
closed short-circuit transformation ratio of 1 / 3 that
removes the component from the zero-sequence
compensated current for the side w. The connection
of the secondary phase of the CT-adapters to the relay
inputs is L3-L1, L1-L2, L2-L3, with the same polarity.
-270
Applied to the w secondary side
of power transformers Dy3, Zy3
where the primary side is the
reference side for phase com-
pensation.
C(w) = 1/√3 0 -1/√3
0 -1/√3 1/√3
-1/√3 1/√3 0
Same as Yd3 adapter CTs with transformation ratio
1 / 3 on the side w. The connection of the second-
ary phase of the CT-adapters to the relay inputs is
L1-L1, L2-L2, L3-L3, with the same polarity.
C(w) = 1/√3 0 -1/√3
0 -1/√3 1/√3
-1/√3 1/√3 0
Same as Yd9 adapter CTs with transformation ratio
1 / 3 on the side w. The connection of the secondary
phase of the CT-adapters to the relay inputs is L1-L1,
L2, L2, L3, L3, with the same polarity.
-300
Applied to the w secondary side
of power transformers Dd2,
Dz2, Zd2 where the primary side
is the reference side for phase
compensation.
C(w) = 0 0 -1
0 -1 0
-1 0 0
Same as Yy0 adapter CTs with transformation
ratio 1/1 on the side w. The connection of the
secondary phase of the CT-adapters to the relay
inputs is L2-L1, L3-L2, L1-L3, with reverse polarity.
C(w) = 1/3 1/3 -2/3
1/3 -2/3 1/3
-2/3 1/3 1/3
Same as Yy0 adapter CTs with transformation ratio 1 / 1
on the side we connected with the tertiary delta closed
short-circuit transformation ratio of 1 / 3 that removes
the component from the zero-sequence compensated
current for the side w. The connection of the second-
ary phase of the CT-adapters to the relay inputs is
L2-L1, L3-L2, L1-L3, with reverse polarity.
-330
Applied to the w secondary side
of power transformers Dy1, Zy1
where the primary side is the
reference side for phase com-
pensation.
C(w) = 0 1/√3 -1/√3
1/√3 -1/√3 0
-1/√3 0 1/√3
Same as Yd11 adapter CTs with transformation
ratio 1 / 3 on the side w. The connection of the
secondary phase of the CT-adapters to the relay
inputs is L1-L1, L2-L2, L3-L3, with the same polarity.
C(w) = 0 1/√3 -1/√3
1/√3 -1/√3 0
-1/√3 0 1/√3
Same as Yd11 adapter CTs with transformation ratio
1 / 3 on the side w. The connection of the secondary
phase of the CT-adapters to the relay inputs is L1-L1,
L2, L2, L3, L3, with the same polarity.
