284
NVA100X-D - Manual - 02 - 2016
MEASURES, LOGIC STATES AND COUNTERS
System diagnostic OK/NOT OK
Device diagnostic OK/NOT OK
Program diagnostic OK/NOT OK
Data-base boot OK/NOT OK
Data-base runtime OK/NOT OK
DSP boot OK/NOT OK
DSP run-time OK/NOT OK
Memory boot OK/NOT OK
Memory run-time OK/NOT OK
Data Bus heavy OK/NOT OK
PLC boot OK/NOT OK
PLC run-time OK/NOT OK
Protection I/O assigned verify startup OK/NOT OK
Protection I/O assigned verify run-time major OK/NOT OK
Total protection I/O assigned not-matching 0
Protection I/O assigned not-matching
PLC I/O assigned not-matching OK/NOT OK
PLC I/O assigned not-matching run-time major OK/NOT OK
Total PLC I/O assigned not-matching 0
PLC I/O assigned not-matching
When a higher level anomaly is recognized all protective functions are disabled and the output relays
switch in no-trip state:
rest state if the output relay are set in De-energized mode (contacts as shown in the diagrams)
active state if the output relay are set in Energized mode (opposite to what is shown in the dia-
grams).
The connections of the trip and diagnostic relays must be performed according to the application:
when the output relay must be normally energized and the circuit breaker must be open in case of
failure of the protection system, the self-test function must be enabled and assigned to the normally
energized relay selected for tripping.
The diagnostic alarms can be allocated to an output relay; for this purpose the Self-test relay pa-
rameter can be set inside the Set \ Self-test Relay submenu.
Pilot wire diagnostic
Detailed diagnostic information about the pilot wire are available.
(Read \ Pilot wire diagnostic).
BLIN1 pilot wire breaking diagnostic state ON/OFF
Pilot wire BLIN1 shorted ON/OFF
Selective Block - BLOCK2
The input and output state concerning the selective block are available (Read \ Selective block-
BLOCK2).
Block2 input
Phase protections input selective block state BLK2IN-Iph ON/OFF
Ground protections input selective block state BLK2IN-IE ON/OFF
tB-Iph/IE Elapsed state tB timeout ON/OFF
Block2 output
Starting state of phase protections enabled
for external selective block on output ST-Iph-BLK2 ON/OFF
Starting state of ground protections enabled
for external selective block on output ST-IE-BLK2 ON/OFF
Phase protections output
selective block state BLK2-OUT-Iph ON/OFF
Ground protections
output selective block state BLK2-OUT-IE ON/OFF
Phase and ground protections
output selective block state BLK2-OUT-Iph/IE ON/OFF
Fault recording - SFR
Recording is triggered by one or more causes (up to 8 simultaneous):
Fault counter
Date and time
Fault cause
Maximum current between I
L1Lrms
-I
L2Lrms
-I
L3Lrms
I
LmaxL-rms-r
Phase RMS currents side L I
L1Lr
, I
L2Lr
, I
L3Lr
Phase RMS currents side H I
L1Hr
, I
L2Hr
, I
L3Hr
Phase voltages U
L1r
, U
L2r
, U
L3r
Phase-to-phase voltages U
12r
, U
23r
, U
31r
Residual current side 1 I
E1r
Calculated residual current side L I
ECLr
Residual current side 2 I
E2r
Calculated residual current side H I
ECHr
Stabilization current side H I
ESHr
Residual voltage U
Er
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
—
•
•
—
•
•
•
•
•
•
•
•
•
—
