Thytronic Pro-N NVA100X-D

TECHNICAL DATA
39
NVA100X-D - Manual - 02 - 2016
CT supervision - 74CT side L
74CT Threshold (S
(L)
<) 0.10...0.95 (step 0.01)
74CT(L) Overcurrent threshold (I
(L)*
) 0.10...1.00 I
nL
(step 0.01 I
nL
)
Operating time delay (t
S (L )
<) 0.03...200 s
0.03...9.99 s (step 0.01 s)
10.0...99.9 s (step 0.1 s)
100...200 s (step 1 s)
Dropout ratio for the I
(L)*
pickup 0.95...0.98
Dropout time ≤ 0.05 s
Pickup accuracy I
(L)*
± 0.5% with 0.1 I
nL
± 0.2% with 1 I
nL
Operate time accuracy 5% or ± 10 ms
Pilot wire diagnostic
BLOUT1 Diagnostic pulse period (PulseBLOUT1) OFF-0.1-1-5-10-60-120 s
BLIN1 Diagnostic pulse control time interval (PulseBLIN1) OFF-0.1-1-5-10-60-120 s
Demand measures
Fix on demand period (t
FIX)
1...60 min (step 1 min)
Rolling on demand period (t
ROL)
1...60 min (step 1 min)
Number of cycles for rolling on demand (N.
ROL)
1...24 (step 1)
Oscillography (DFR)
[1]
Format COMTRADE
Recording mode
circular
Sampling rate
32 samples / cycle
Trigger setup:
Pre-trigger time
0.05...1.00 s (step 0.01 s)
Post-trigger time
0.05...60.00 s (step 0.05 s)
Set sample channels:
i
L1-H
, i
L2-H
, i
L3-H
, i
L1-L
, i
L2-L
, i
L3-L
, i
E1
,
i
E2
, u
L1
, u
L2
, u
L3
, u
E
, i
L1cH
, i
L2cH
,
i
L3cH
, i
L1cL
, i
L2cL
, i
L3cL
, i
SL1
, i
SL2
,
i
SL3
, i
DL1
, i
DL2
, i
DL3
Set analog channels:
Analog 1...Analog 12 f
U12
, f
U23
, f
U31
,I
L1-H
, I
L2-H
, I
L3-H
, I
L1L
,
I
L2L
, I
L3L
, I
E1
, I
E2
, I
ECH
, I
ECL
, I
DL1
, I
DL2
, I
DL3
, U
L1
, U
L2
, U
L3
, U
12
, U
23
, U
31
, U
E
,U
EC
, DTheta, Phi
L1
, Phi
L2
,
Phi
L3
, Phi
E
, Phi
EC
, I
1
, I
2
/I
1
, U
1
, U
2
, P, Q, S, CosPhi, P
L1
, P
L2
, P
L3
, Q
L1
, Q
L2
, Q
L3
, CosPhi
L1
, CosPhi
L2
,
CosPhi
L3
, I
L1-2nd
, I
L2-
I
2nd
, I
L3-2nd
, I
-2nd
/I
L
, T
1
...T
8
Set digital channels:
Binary 1...Binary 16 digital channels KC1-1... KC1-8, KC2-1... KC2-8,
IN1-1...IN1-16, IN2-1...IN2-16
[2]
Binary 17...Binary 32 digital channels (87T states)
ST Id>_L1, ST Id>_L2, ST Id>_L3,
TR Id>_L1, TR Id>_L2, TR Id>_L3, ST Id>>_L1, ST Id>>_L2, ST Id>>_L3, TR Id>>_L1, TR Id>>_L2,
TR Id>>_L3, ST 2nd-REST, ST 5th-REST, ST H-REST-L1, ST H-REST-L2, ST H-REST-L3, ST SatDet
Note 1 For the DFR function a licence is required; call Thytronic for purchasing.
Note 2 Output relay and binary input states are available only when the concerning I/O circuits are implemented
—
—
—
—
