Thytronic Pro-N NVA100X-D - APPENDIX C1 - Pro-NX Dimensions; FLUSH MOUNTING CUTOUT; RACK MOUNTING

374
NVA100X-D - Manual - 02 - 2016
APPENDIX
8.9 APPENDIX C1 - Pro-NX Dimensions
FLUSH MOUNTING CUTOUT
SIDE VIEW
REAR VIEW
FRONT VIEW
177
215
222
20
210 ±0.3
164.4
158.0
±0.3
189
94.5
N.4 holes ø 4.2
RACK MOUNTING
N.4 holes ø 4.2
156
164.4
177
207
189
215
IN2D IN1C OC1EOC2F
NVA100-DX#MM00
I
n
5A
U
AUX
110-230 Vac/dc
100V
100V
I
En
U
En
U
n
1A 1A
5A 1A
5A
177 (4U)
101.6
482.6
465
