Protection states
For each protection threshold, the following data are available:
Start ON/OFF
Trip ON/OFF
Logic block (Block1) ON/OFF
Selective block (Block2) ON/OFF
Cold Load Pickup ON/OFF
Delayed inputs
The binary input states, acquired downstream the delay timers are available:
IN1-1 ON/OFF
IN1-2 ON/OFF
INx-x ON/OFF
Internal states
The state of the functions assigned to binary inputs are available
Reset LEDs ON/OFF
Profile selection ON/OFF
Fault trigger ON/OFF
IE /IPh Block2 ON/OFF
IPh Block2 ON/OFF
IE Block2 ON/OFF
Logic block side H-L and 87GMT ON/OFF
Logic block side H ON/OFF
Logic block side L ON/OFF
Blocco logico 87GMT ON/OFF
TCS1 (Trip Circuit Supervision) ON/OFF
TCS2 (Trip Circuit Supervision) ON/OFF
Trip External protections ON/OFF
Reset partial counters ON/OFF
Reset CB Monitor data ON/OFF
52a ON/OFF
52b ON/OFF
Open CB ON/OFF
CloseCB ON/OFF
Init DTheta (Thermal image presetting) ON/OFF
Remote trip ON/OFF
MCB VT OPEN ON/OFF
MCB VT2 OPEN) ON/OFF
Reset on demand measures ON/OFF
Reset energy measures ON/OFF
74VT ext.
ON/OFF
Block I(L)> (Logic block side L, active with virtual I/O) BlockI(L)> ON/OFF
Block I(L)>> (Logic block side L, active with virtual I/O) BlockI(L)>> ON/OFF
Block I(L)>>> (Logic block side L, active with virtual I/O) BlockI(L)>>> ON/OFF
Block I(H)> (Logic block side H, active with virtual I/O) BlockI(H)> ON/OFF
Block I(H)>> (Logic block side H, active with virtual I/O) BlockI(H)>> ON/OFF
Block I(H)>>> (Logic block side H, active with virtual I/O) BlockI(H)>>> ON/OFF
Block IE1> (Logic block side 1, active with virtual I/O) BlockIE1> ON/OFF
Block IE1>> (Logic block side 1, active with virtual I/O) BlockIE1>> ON/OFF
Block IE1>>> (Logic block side 1, active with virtual I/O) BlockIE1>>> ON/OFF
Block IE2> (Logic block side 2, active with virtual I/O) BlockIE2> ON/OFF
Block IE2>> (Logic block side 2, active with virtual I/O) BlockIE2>> ON/OFF
Block IE2>>>(Logic block side 2, active with virtual I/O) BlockIE2>>> ON/OFF
IEC>Bk (Logic block IEC>, active with virtual I/O) BlockIEC> ON/OFF
IEC>>Bk ((Logic block IEC>, active with virtual I/O) BlockIEC>> ON/OFF
IEC>>>Bk (Logic block IEC>>>, active with virtual I/O) BlockIEC>>> ON/OFF
IED>Bk (Logic block IED>, active with virtual I/O) BlockIED> ON/OFF
IED>>Bk (Logic block IED>, active with virtual I/O) BlockIED>> ON/OFF
IED>>>Bk (Logic block IED>, active with virtual I/O) BlockIED>>> ON/OFF
Speed control ON/OFF
Reset N/T starts (reset timer counter motor start) ON/OFF
Motor re-acceleration ON/OFF
Reset running motor time (Partial) ON/OFF
Reset running motor time (Total) ON/OFF
—
•
•
•
•
•
—
•
•
•
—
