Thytronic Pro-N NVA100X-D - APPENDIX B2 - Interfaces

368
NVA100X-D - Manual - 02 - 2016
APPENDIX
8.6 APPENDIX B2 - Interfaces
Interfaces.ai
FRONT PANEL
Supervision
unit
5
6
RS485
A+
B-
X
TX
[1]
TX
[1]
ETHERNET
TX
[1]
FX
[1]
ETHERNET
FX
[1]
FX
[1]
ETHERNET
Note [1]
two redundant ports with hw-sw switching
selectable from TX (RJ45) + FX (optical fiber), TX + TX or FX + FX
A version with two simultaneously active Ethernet ports with RSTP protocol is available
