FUNCTION CHARACTERISTICS
Summary of elements where second harmonic restraint and Cold Load Pickup functions may be enabled—
Cold Load Pickup - CLP
Second harmonic restraint - 2ndh-REST
PROTECTIVE ELEMENTS
Negative sequence for Line-Transformer - 46M I2> Element
gg
Negative sequence for Line-Transformer - 46M I2>> Element
gg
Thermal image for Line-Transformer- 49LT DthAL1 Alarm Element
g
Thermal image for Line-Transformer DthAL2 Alarm Element
g
Thermal image for Line-Transformer - 49 Dth> Element
g
Phase overcurrent side H - 50/51 I(H)> Element
gg
Phase overcurrent side H - 50/51 I(H)>> Element
gg
Phase overcurrent side H - 50/51 I(H)>>> Element
gg
Phase overcurrent side L - 50/51 I(L)> Element
gg
Phase overcurrent side L - 50/51 I(L)>> Element
gg
Phase overcurrent side L - 50/51 I(H)>>> Element
gg
Residual overcurrent - 50N.1/51N.1 IE1> Element
gg
Residual overcurrent - 50N.1/51N.1 IE1>> Element
gg
Residual overcurrent - 50N.1/51N.1 IE1>>> Element
gg
Residual overcurrent - 50N.2/51N.2 IE2> Element
gg
Residual overcurrent - 50N.2/51N.2 IE2>> Element
gg
Residual overcurrent - 50N.2/51N.2 IE2>>> Element
gg
Calculated residual overcurrent - 50N(Comp)/51N(Comp)/ IEC> Element
gg
Calculated residual overcurrent - 50N(Comp)/51N(Comp)/ IEC>> Element
gg
Calculated residual overcurrent - 50N(Comp)/51N(Comp)/ IEC>>> Element
gg
Directional earh fault - 67N IED> Element
g
Directional earh fault - 67N IED>> Element
g
Directional earh fault - 67N IED>>> Element
g
Directional earh fault - 67N IED>>>> Element
g
Calculated directional earh fault - 67NC IEDC> Element
g
Calculated directional earh fault - 67NC IEDC>> Element
g
Calculated directional earh fault - 67NC IEDC>>> Element
g
Calculated directional earh fault - 67NC IEDC>>> Element
g
