314
NVA100X-D - Manual - 02 - 2016
SETTING AND COMMISSIONING
NVA100X-D_menuset3.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
PROCEED SET MENU’
SET
PROFILE A
PROCEED PROFILE A MENU’
49MG >>
Common >>
DthIN 0.0 DThetaB
KST 2.0
K2 0
T+ 10 min
T- 1.0 T+
DthCLP Mode OFF
tDthCLP 0.10 s
DthAL1 Element >>
DthAL1 Enable OFF
DthAL1 0.5 DThetaB
DthAL1BLK1 OFF
DthAL1BLK2IN OFF
DthAL1BLK2OUT OFF
DthAL1BLK4 OFF
Relays DthAL1
DthAL1-K -
LEDs DthAL1
DthAL1-L -
DthAL2 Enable OFF
DthAL2 1.0 DThetaB
DthAL2BLK1 OFF
DthAL2BLK2IN OFF
DthAL2BLK2OUT OFF
DthAL2BLK4 OFF
Relays DthAL2
DthAL2-K -
LEDs DthAL2
DthAL2-L -
DthAL2 Element >>
Dth> Enable OFF
Dth> 1.200 DThetaB
Dth>BLK1 OFF
Dth>BLK2IN OFF
Dth>BLK2OUT OFF
Dth>BLK4 OFF
Dth>BF OFF
Dth>disby50-51 OFF
Relays Dth>
Dth>-K -
LEDs Dth>
Dth>-L -
Dth> Element >>
50/51 >>
I> Element >>
I>> Enable OFF
Type
Characteristic:
I>>Curve DEFINITE
ICLP>> Mode OFF
tCLP>> 0.10 s
t>>RES 0.00 s
I>>def OFF
1.00 In
ICLP>>def 2.00 In
t>>def 1.00 s
I>>inv OFF
1.00 In
ICLP>inv 2.00 In
t>>inv 5 s
I>>BLK1 OFF
I>>BLK2IN OFF
I>>BLK2OUT OFF
I>>BLK4 OFF
I>>2ndh-REST OFF
I>>BF OFF
I>disbyI>> OFF
Relays I>>
I>>ST-K -
I>>TR-K -
LEDs I>>
I>>ST-L -
I>>TR-L -
I> Enable OFF
Type
Characteristic:
I>Curve DEFINITE
ICLP> Mode OFF
tCLP> 0.10 s
t>RES 0.00 s
I>def OFF
1.00 In
ICLP>def 2.00 In
t>def 1.00 s
I>inv OFF
1.00 In
ICLP>inv 2.00 In
t>inv 10.0 s
I>BLK1 OFF
I>BLK2IN OFF
I>BLK2OUT OFF
I>BLK4 OFF
I>2ndh-REST OFF
I>BF OFF
Relays I>
I>ST-K -
I>TR-K -
LEDs I>
I>ST-L -
I>TR-L -
I>>> Enable OFF
ST-I>>>&ST-U<< OFF
ICLP>>> Mode OFF
tCLP>>> 0.10 s
t>>>RES 0.00 s
I>>>def OFF
1.00 In
ICLP>>>def 2.00 In
t>>>def 1.00 s
I>>>BLK1 OFF
I>>>BLK2IN OFF
I>>>BLK2OUT OFF
I>>>BLK4 OFF
I>>>2ndh-REST OFF
I>>>BF OFF
I>disbyI>>> OFF
I>>disbyI>>> OFF
Relays I>>>
I>>>ST-K -
I>>>TR-K -
LEDs I>>>
I>>>ST-L -
I>>>TR-L -
I>> Element >>
I>>> Element >>
ILR> Enable OFF
Mode51LR>
No speed crt1
ILR>inv 0.80 IB
I-MOT-ST 1.00 IB
tLR>inv 10.0 s
ILR>BLK1 OFF
ILR>BLK2IN OFF
ILR>BLK2OUT OFF
ILR>BF OFF
Relays ILR>
ILR>ST-K -
ILR>TR-K -
LEDs ILR>
ILR>ST-L -
ILR>TR-L -
ILR>> Enable OFF
Mode51LR>>
No speed crt1
tLRCLP>> 0.10 s
ILR>>def 1.00 IB
tLR>>def 1.00 s
ILR>BLK1 OFF
ILR>>BLK2IN OFF
ILR>>BLK2OUT OFF
ILR>>BF OFF
Relays ILR>>
ILR>>ST-K -
ILR>>TR-K -
LEDs ILR>>
ILR>>ST-L -
ILR>>TR-L -
51LR(48)/14 >>
ILR> Element >>
ILR>> Element >>
t-I/U>RES 0 s
I-I/U>def enable
OFF
I-I/U>def 1.00 In
t-I/U>def 1.00 s
I-I/U>BLK1 OFF
I-I/U>BLK2IN OFF
I-I/U>BLK2OUT OFF
I-I/U>BF OFF
Relays I-I/U>
I-I/U>ST-K -
I-I/U>TR-K -
LEDs I-I/U>
I-I/U>ST-L -
I-I/U>TR-L -
t-I/U>>RES 0.00 s
I-I/U>>def enable
OFF
I-I/U>>def 1.00 In
t-I/U>>def 1.00 s
I-I/U>>BLK1 OFF
I-I/U>>BLK2IN OFF
I-I/U>>BLK2OUT OFF
I-I/U>BF OFF
I-I/U>disbyI-I/U>>
OFF
Relays I-I/U>>
I-I/U>>ST-K -
I-I/U>>TR-K -
LEDs I-I/U>>
I-I/U>>ST-L -
I-I/U>>TR-L -
Mode51V
Voltage controlled
U-I/U< 0.50 Un
U-I/U-1< 0.80 Un
U-I/U-2< 0.50 Un
K 1.00
51V >>
Common >>
I-I/U> Element >>
I-I/U>> Element >>
