SAWMILL ASSEMBLY
Saw Head Installation
SAWMILL ASSEMBLY 15doc110819 3-19
3
6. Attach the power cord bracket to the rear mast tube as shown below. Bolt the rear mast tube with
the attached bracket to the mast upright on the engine side.
7. Mount the mast support tubes as shown in the figure below.
Rear Mast Tube
Power Cord Bracket
Sawmill Mast
