ﺩﺎﻌﺑﻸﻟ ﻲﻧﺎﻴﺑ ﻢﺳﺭ .١٦
ΔλϭΑ˼˼
ΔλϭΑ˼˽˽
ΔλϭΑ˺˿˾˽˽˻˹
ΔλϭΑ˺˽˻˼˿˹˿
ΔλϭΑ˺˻˿˼˻˽
˻˻
ΔλϭΑ˹)
ΔλϭΑ˻˺˾˾˼
ΔλϭΑ˻˹˺˾˺
ΔλϭΑ˼  ˼˿
ΔλϭΑ˼

˼˿
ΔλϭΑ˼

˽˼

˻
[RC-03]
ﺭﺎﻴﺘﻟﺍ ﺭﺪﺼﻣ(MX-6224D ﻦﻣ ﺩﻭﺰﻣ) ﻂﻟﻮﻓ ٥ ﺮﺷﺎﺒﻣ ﺭﺎﻴﺗ
ﺭﺎﻴﺘﻟﺍ ﻙﻼﻬﺘﺳﺍﻰﺼﻗﺃ ﺪﺤﻛ ﺮﻴﺒﻣﺃ ﻲﻠﻴﻣ ١٢٠
ﻞﻴﺻﻮﺗ ﻑﺮﻃRJ-45 ﻞﺻﻮﻤﻟﺍ
ﻢﻜﺤﺘﻟﺍ ﺢﻴﺗﺎﻔﻣ ﻲﻠﺧﺍﺪﻟﺍ ﻕﺎﻄﻨﻟﺎﺑ ﺹﺎﺨﻟﺍ (ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺘﻟﺎﺑ ﻢﻜﺤﺘﻟﺍ ﺡﺎﺘﻔﻣ ١
ﻲﺟﺭﺎﺨﻟﺍ ﻕﺎﻄﻨﻟﺎﺑ ﺹﺎﺨﻟﺍ (ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺘﻟﺎﺑ ﻢﻜﺤﺘﻟﺍ ﺡﺎﺘﻔﻣ ١
ﺕﺍﺮﺛﺆﻤﻟﺎﺑ ﺹﺎﺨﻟﺍ (ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺘﻟﺎﺑ ﻢﻜﺤﺘﻟﺍ ﺡﺎﺘﻔﻣ ١
ﺕﺍﺮﺷﺆﻤﻟﺍﻞﻴﺻﻮﺘﻟﺍ ﺮﺷﺆﻣ
ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺩ ﻕﺎﻄﻨﻠﻟ (ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺘﻟﺍ ﺝﺮﺧ
ﺕﺍﺮﺛﺆﻤﻠﻟ (ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺗ
ﻞﻴﺻﻮﺘﻟﺍ ﻞﺒﻛ(CAT5-STP ) LAN ﺔﻴﻠﺤﻤﻟﺍ ﺔﻜﺒﺸﻠﻟ CAT 5 ﻦﻣ ﻲﻤﺤﻣ ﻱﻮﺘﻠﻣ ﺝﻭﺰﺑ ﻢﻴﻘﺘﺴﻣ ﻞﺒﻛ
(CAT5-UTP ) LAN ﺔﻴﻠﺤﻤﻟﺍ ﺔﻜﺒﺸﻠﻟ CAT 5 ﻦﻣ ﻲﻤﺤﻣ ﺮﻴﻏ ﻱﻮﺘﻠﻣ ﺝﻭﺰﺑ ﻢﻴﻘﺘﺴﻣ ﻞﺒﻛ
ﻞﺒﻜﻠﻟ ﻝﻮﻃ ﻰﺼﻗﺃﻡ ٢٠٠
ﺔﻴﻠﻴﻐﺸﺘﻟﺍ ﺓﺭﺍﺮﺤﻟﺍ ﺔﺟﺭﺩ(ﻑ°١٠٤ ﻰﻟﺇ ٣٢) ﻡ°٤٠ ﻰﻟﺇ ٠
ﺔﻴﻠﻴﻐﺸﺘﻟﺍ ﺔﺑﻮﻃﺮﻟﺍ(ﻒﺛﺎﻜﺗ ﻥﻭﺪﺑ) ٪٨٠ ﻰﻟﺇ ٣٥ ﺔﻴﺒﺴﻨﻟﺍ ﺔﺑﻮﻃﺮﻟﺍ
ﺩﺎﻌﺑﻷﺍ(ﺔﺻﻮﺑ ٣,٤٣ × ﺔﺻﻮﺑ ٢,١٨ × ﺔﺻﻮﺑ
٣,٣٩) ﻢﻣ (ﻖﻤﻋ) ٨٧,٢ × (ﻉﺎﻔﺗﺭﺍ) ٥٥,٣ × (ﺽﺮﻋ) ٨٦
ﻥﺯﻮﻟﺍ(ﻞﻃﺭ ٠,٨٤) ﻡﺍﺮﺟ ٣٨٠
ﺐﻴﻄﺸﺘﻟﺍءﻼﻃ ،(RAL 9016 ﻝﺩﺎﻌﻳ) ﺾﻴﺑﺃ ،ﺔﻴﻠﻄﻣ ﺔﻳﺫﻻﻮﻓ ﺔﺤﻴﻔﺻ
ﺕﺎﻴﻟﺎﻤﻜﻟﺍ
•
١ ..................................ﺔﻴﺑﺮﻌﻟﺍ ﺔﻐﻠﻟﺎﺑ ﻥﺎﻴﺑ ﻖﺼﻠﻣ
ﺔﻳﺭﺎﻴﺘﺧﻻﺍ ﺕﺎﺠﺘﻨﻤﻟﺍ
•
P-2240 :ﻲﻓﺎﺿﺍ ﺕﻮﺻ ﻢﺨﻀﻣ
DA-250FH :ﺕﺍﻮﻨﻘﻟﺍ ﺩﺪﻌﺘﻣ ﻲﻓﺎﺿﺍ ﺕﻮﺻ ﻢﺨﻀﻣ
DM-1300 :ﻲﻜﻴﻣﺎﻨﻳﺪﻟﺍ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
EM-410 :ﺭﺪﺼﻟﺍ ﻰﻠﻋ ﺖﺒﺜﻤﻟﺍ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
TC-651M ،TC-631M :ﻕﻮﺒﻟﺍ ﺔﻋﺎﻤﺳ
BS-1030W ،BS-1030B :ﺔﻴﻠﺧﺍﺪﻟﺍ ﺔﻋﺎﻤﺴﻟﺍ
MB-25B :ﻞﻣﺎﺤﻟﺍ ﻰﻠﻋ ﺐﻴﻛﺮﺘﻟﺍ ﺔﻔﻴﺘﻛ
PF-013B :ﺔﻳﻮﻬﺘﻠﻟ ﺔﻣﺮﺨﻤﻟﺍ ﺔﺣﻮﻠﻟﺍ
MX-6224D .١.١٦RC-03 .٢.١٦
http://www.toa.jp/ :ﻲﻧﻭﺮﺘﻜﻟﻹﺍ ﻊﻗﻮﻤﻟﺍ
ﻢﻣ :ﺓﺪﺣﻮﻟﺍ
