ﺕﺎﻔﺻﺍﻮﻤﻟﺍ .١٥
[MX-6224D]
ﺭﺎﻴﺘﻟﺍ ﺭﺪﺼﻣﺰﺗﺮﻫ ٦٠/٥٠ ،ﻂﻟﻮﻓ ٢٤٠ - ﻂﻟﻮﻓ ٢٢٠ ﺩﺩﺮﺘﻣ ﺭﺎﻴﺗ
ﺭﺎﻴﺘﻟﺍ ﺝﺮﺧ(ﺮﻳﺎﻌﻤﻟﺍ ﺝﺮﺧ ،ﻡﻭﺃ ٤٢ ،ﻂﻟﻮﻓ ١٠٠) ﺓﺎﻨﻗ ٢ × ﻁﺍﻭ ٢٤٠
ﺭﺎﻴﺘﻟﺍ ﻙﻼﻬﺘﺳﺍ(ﻦﻴﺗﺎﻨﻘﻟﺍ ﻼﻛ ،ﺭﺪﻘﻤﻟﺍ ﺝﺮﺨﻟﺍ ﺪﻨﻋ) ﻁﺍﻭ ٥٧٠ ، (IEC60065 ﻰﻟﺇ
ً
ﺩﺎﻨﺘﺳﺍ) ﻁﺍﻭ ١٠٠
ﺕﻮﺼﻟﺍ ﻢﻴﺨﻀﺗ ﻡﺎﻈﻧﻝﻭﺰﻌﻣ ﻲﻧﺎﻔﻠﻏ ﺝﺮﺧ ﻝﻮﺤﻣ ﻥﻭﺪﺑ ﺝﺮﺧ ،D ﺔﺌﻔﻟﺍ
ﺩﺩﺮﺘﻟﺍ ﺔﺑﺎﺠﺘﺳﺍ
(ﺕﻮﺼﻟﺍ ﻢﺨﻀﻣ ﺔﻗﺎﻃ ﻞﺧﺩ ﻦﻣ ، ﺮﻳﺎﻌﻤﻟﺍ ﻞﻤﺤﻟﺍ ، ﺮﻳﺎﻌﻤﻟﺍ ﺝﺮﺨﻟﺍ ٣/١ ﺪﻨﻋ) ﻞﺒﻴﺴﻳﺩ ٣± ،ﺰﺗﺮﻫﻮﻠﻴﻛ ٢٠ - ﺰﺗﺮﻫ ٥٠
ﻪﻳﻮﺸﺘﻟﺍ(ﺮﻳﺎﻌﻤﻟﺍ ﺭﺎﻴﺘﻟﺍ ﺝﺮﺧ ﺪﻨﻋ ٣/١ ،ﺰﺗﺮﻫﻮﻠﻴﻛ ١ ﺪﻨﻋ) ﻞﻗﺃ ﻭﺃ ٪ ١
ﻞﺧﺪﻟﺍ (OFF ﻕﻼﻏﻹﺍ ﻊﺿﻭ ﻰﻟﺇ ﻡﻮﺘﻧﺎﻓ ﺭﺎﻴﺘﻟﺍ) *ﻞﺒﻴﺴﻳﺩ ٦٠-/(ﻂﻟﻮﻓ ٢٤ ﺓﺭﺪﻘﺑ ﻡﻮﺘﻧﺎﻓ ﺭﺎﻴﺘﻟﺎﺑ ﻞﻤﻌﻳ) *ﻞﺒﻴﺴﻳﺩ ٥٠- :١ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
(ﻥﺯﺍﻮﺘﻣ :3P) ﻢﻣ ٦,٣ ﺮﻄﻘﺑ ﻒﺗﺎﻫ ﺲﺑﺎﻗ ،ﺎ
ً
ﻴﻧﻭﺮﺘﻜﻟﺇ ﻥﺯﺍﻮﺘﻣ ،ﻡﻭﺃ ٦٠٠
،ﺎ
ً
ﻴﻧﻭﺮﺘﻜﻟﺇ ﻥﺯﺍﻮﺘﻣ ،ﻡﻭﺃ ٢٠٠ ،*ﻞﺒﻴﺴﻳﺩ ٦٦- :٤ - ٢ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
(ﻡﺍﺪﺨﺘﺳﻻﺍ ﺢﻟﺎﺻ ﺎﻤﻬﻨﻣ ﻱﺃ) (ﻥﺯﺍﻮﺘﻣ :3P) ﻢﻣ ٦,٣ ﺮﻄﻘﺑ ﻒﺗﺎﻫ ﺲﺑﺎﻗﻭ XLR-3-31 ﺯﺍﺮﻃ
،ﺎ
ً
ﻴﻧﻭﺮﺘﻜﻟﺇ ﻥﺯﺍﻮﺘﻣ ،ﻡﻭﺃ ٦٠٠ ،*ﻞﺒﻴﺴﻳﺩ ٦٠- :٦ - ٥ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
(ﻡﺍﺪﺨﺘﺳﻻﺍ ﺢﻟﺎﺻ ﺎﻤﻬﻨﻣ ﻱﺃ) (ﻥﺯﺍﻮﺘﻣ :3P) ﻢﻣ ٦,٣ ﺮﻄﻘﺑ ﻒﺗﺎﻫ ﺲﺑﺎﻗﻭ XLR-3-31 ﺯﺍﺮﻃ
(ﺪﺣﺍﻭ ﺝﻭﺯ) RCA ﺔﻳﺭﻮﺤﻣ ﺕﺎﺴﺑﺎﻗ ،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻂﻠﺘﺨﻣ ﻱﺩﺎﺣﺃ ﻡﻭﺃ ﻮﻠﻴﻛ ١٠ ،*ﻞﺒﻴﺴﻳﺩ ١٠- :١ ﻲﻓﺎﺿﺇ
،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻂﻠﺘﺨﻣ ﻱﺩﺎﺣﺃ ﻡﻭﺃ ﻮﻠﻴﻛ ١٠ ،*ﻞﺒﻴﺴﻳﺩ ٢٠- :٢ ﻲﻓﺎﺿﺇ
(ﻮﻳﺮﻴﺘﺳ :3P) ﻢﻣ ٣,٥ ﺮﻄﻘﺑ ﺮﻴﻐﺻ ﺲﺑﺎﻗ
:ﻲﻓﺎﺿﻻﺍ ﺕﻮﺼﻟﺍ ﻢﺨﻀﻣ ﺔﻗﺎﻃ ﻞﺧﺩ
،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻡﻭﺃ ﻮﻠﻴﻛ ١٠ ،*ﻞﺒﻴﺴﻳﺩ ٠
(ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺩ ﺝﺭﺎﺨﻤﻟﺍ ﻦﻣ ﻞﻜﻟ ١) RCA ﺔﻳﺭﻮﺤﻤﻟﺍ ﺕﺎﺴﺑﺎﻘﻟﺍ
ﺝﺮﺨﻟﺍ M4 ﻞﻴﺻﻮﺗ ﻑﺮﻃ ﻲﻏﺮﺑ ،ﻥﺯﺍﻮﺘﻣﻭ ﻝﻭﺰﻌﻣ ﻲﻧﺎﻔﻠﻏ،(ﻡﻭﺃ ٤٢) ﻂﻟﻮﻗ ١٠٠ ،ﻕﺎﻄﻧ ٢ :ﺔﻋﺎﻤﺴﻟﺍ ﺝﺮﺧ
(ﺪﺣﺍﻭ ﺝﻭﺯ) RCA ﺔﻳﺭﻮﺤﻣ ﺕﺎﺴﺑﺎﻗ ،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻱﺩﺎﺣﺃ ﻡﻭﺃ ٦٠٠ ،*ﻞﺒﻴﺴﻳﺩ ٠ :ﻞﻴﺠﺴﺘﻟﺍ ﺝﺮﺧ
(ﺪﺣﺍﻭ ﺝﻭﺯ) RCA ﺔﻳﺭﻮﺤﻣ ﺕﺎﺴﺑﺎﻗ ،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻱﺩﺎﺣﺃ ﻡﻭﺃ ٦٠٠ ،*ﻞﺒﻴﺴﻳﺩ ٠ :ﺕﺍﺮﺛﺆﻤﻟﺍ ﻞﻗﺎﻧ ﺝﺮﺧ
،ﻥﺯﺍﻮﺘﻣ ﺮﻴﻏ ،ﻱﺩﺎﺣﺃ ﻡﻭﺃ ٦٠٠ ،*ﻞﺒﻴﺴﻳﺩ ٠ :ﻲﻟﻭﻷﺍ ﺕﻮﺼﻟﺍ ﻢﺨﻀﻣ ﺝﺮﺧ
(ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺩ ﺝﺭﺎﺨﻤﻟﺍ ﻦﻣ ﻞﻜﻟ ١) RCA ﺔﻳﺭﻮﺤﻤﻟﺍ ﺕﺎﺴﺑﺎﻘﻟﺍ
ﻡﻮﺘﻧﺎﻓ ﺭﺎﻴﺗ ٦ - ٢ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ XLR-3-31 ﺯﺍﺮﻃ ﺕﻼﺻﻮﻣﻭ (ON/OFF) ﻕﻼﻏﻹﺍ/ﻞﻴﻐﺸﺘﻟﺍ ﻊﺿﻭ ﻰﻟﺇ ﻩﺮﻳﻭﺪﺗ ﻦﻜﻤﻳ ﻱﺬﻟﺍ ١ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ
ءﺎﺿﻮﻀﻟﺍ ﻰﻟﺇ ﺓﺭﺎﺷﻹﺍ ﺔﺒﺴﻧ(ﺔﻘﻴﻗﺩ :ﺕﻮﺼﻟﺎﺑ ﻢﻜﺤﺘﻟﺍ ﺢﻴﺗﺎﻔﻣ ﻊﻴﻤﺟ) ﺮﺜﻛﺃ ﻭﺃ ﻞﺒﻴﺴﻳﺩ ٦٠
ﻢﻜﺤﺘﻟﺍ ﺢﻴﺗﺎﻔﻣ،ﻲﻓﺎﺿﺇ ﻲﻓ ﻢﻜﺤﺘﻠﻟ ﻦﻴﺣﺎﺘﻔﻣ ،ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ ﺕﻮﺻ ﻯﻮﺘﺴﻤﺑ ﻢﻜﺤﺘﻠﻟ ﺢﻴﺗﺎﻔﻣ ٦
ﻲﺟﺭﺎﺧ ﺝﺮﺧ ﺡﺎﺘﻔﻣ ١ ،ﻲﻠﺧﺍﺩ ﺕﻮﺻ ﻯﻮﺘﺴﻤﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١ ،ﻲﻠﺧﺍﺩ ﺝﺮﺧ ﺡﺎﺘﻔﻣ ١
.ﺕﺍﺮﺛﺆﻤﻟﺍ ﻞﻗﺎﻨﻟ (٪ ١٠٠ ﻰﻟﺇ ٠) ﺕﺍﺮﺛﺆﻤﻟﺎﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١ ،ﻲﺟﺭﺎﺧ ﺕﻮﺻ ﻯﻮﺘﺴﻤﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١
،(ﺮﻴﺧﺄﺗ/ﺔﺣﻮﻟ/ﺔﻋﺎﻗ/ﺔﺒﻗ) ﺎ
ً
ﻘﺒﺴﻣ ﻁﻮﺒﻀﻤﻟﺍ ﺕﺍﺮﺛﺆﻤﻟﺍ ﻉﻮﻧ ﺭﺎﻴﺘﺧﺍ ﺡﺎﺘﻔﻣ ١
،(OFF ﻕﻼﻏﻹﺍ ﻊﺿﻭ/ﺮﻴﺼﻗ/ﻂﺳﻮﺘﻣ/ﻞﻳﻮﻃ) ﻲﻨﻣﺯ ﺮﻴﺧﺄﺗ/ﻲﻠﺧﺍﺪﻟﺍ ﻢﺠﺤﻟﺍ ﺕﺍﺮﺛﺆﻣ ﺭﺎﻴﺘﺧﺍ ﺡﺎﺘﻔﻣ ١
،((ON/OFF) ﻕﻼﻏﺇ/ﻞﻴﻐﺸﺗ) ﺕﺍﺮﺛﺆﻤﻟﺍ ﺝﺮﺧ ﻉﻮﻧ ﺭﺎﻴﺘﺧﺍ ﺡﺎﺘﻔﻣ ١
،٦ - ٥ ﻥﻮﻓﻭﺮﻜﻴﻤﻟﺍ ﺮﺛﺆﻣ ﺡﺎﺘﻔﻣ ١
،٦ - ١ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ (ﺰﺗﺮﻫ ٨٠ ،ﻞﺒﻴﺴﻳﺩ ١٥±) ﺾﻔﺨﻨﻤﻟﺍ ﻝﺩﺎﻌﻤﻟﺎﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١
،٦ - ١ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ (ﺰﺗﺮﻫﻮﻠﻴﻛ ٢,٥ ،ﻞﺒﻴﺴﻳﺩ ١٥±) ﻂﺳﻮﺘﻤﻟﺍ ﻝﺩﺎﻌﻤﻟﺎﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١
،٦ - ١ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ (ﺰﺗﺮﻫﻮﻠﻴﻛ ١٢ ،ﻞﺒﻴﺴﻳﺩ ١٥±) ﻲﻟﺎﻌﻟﺍ ﻝﺩﺎﻌﻤﻟﺎﺑ ﻢﻜﺤﺗ ﺡﺎﺘﻔﻣ ١
،ﻲﺟﺭﺎﺧ ﺝﺮﺨﻠﻟ (TC-651M ،TC-631M) ﺔﻋﺎﻤﺴﻟﺍ ﻝﺩﺎﻌﻣ ﺡﺎﺘﻔﻣ ١
،ﺭﺎﻴﺗ ﺡﺎﺘﻔﻣ ١ ،ﻲﻠﺧﺍﺩ ﺝﺮﺨﻠﻟ (BS-1030W ،BS-1030B) ﺔﻋﺎﻤﺴﻟﺍ ﻝﺩﺎﻌﻣ ﺡﺎﺘﻔﻣ ١
(XLR-3-31) ٦ - ٢ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ ﻡﻮﺘﻧﺎﻔﻟﺍ ﺡﺎﺘﻔﻣ
١ ،١ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ ﻡﻮﺘﻧﺎﻔﻟﺍ ﺡﺎﺘﻔﻣ ١
ﺕﺍﺮﺷﺆﻤﻟﺍﻥﻮﻜﺴﻟﺍ ﺮﺷﺆﻣ
ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺪﻟ (ﻞﺒﻴﺴﻳﺩ ٠ ﻭ ﻞﺒﻴﺴﻳﺩ ٢٠- ،ﺔﻄﻘﻧ ٢) ﺝﺮﺨﻟﺍ ﻯﻮﺘﺴﻣ ﺕﺍﺩﺍﺪﻋ
ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺩ ﺕﻮﺼﻟﺍ ﺕﺎﻤﺨﻀﻤﻟ ﺔﻳﺎﻤﺤﻟﺍ ﺕﺍﺮﺷﺆﻣ
ﻲﺟﺭﺎﺧﻭ ﻲﻠﺧﺍﺩ ﻕﺎﻄﻨﻠﻟ ﺝﺮﺨﻟﺍ ﺕﺍﺮﺷﺆﻣ
٦ - ١ ﻥﻮﻓﻭﺮﻜﻴﻤﻠﻟ ﺕﺍﺮﺛﺆﻣ ﺮﺷﺆﻣ
ﺔﻳﻮﻬﺘﻟﺍﻲﻌﻴﺒﻄﻟﺍ ءﺍﻮﻬﻟﺍ ﺪﻳﺮﺒﺗ
ﺔﻴﻠﻴﻐﺸﺘﻟﺍ ﺓﺭﺍﺮﺤﻟﺍ ﺔﺟﺭﺩ(ﻑ° ١٠٤ ﻰﻟﺇ ٣٢) ﻡ° ٤٠ ﻰﻟﺇ ٠
ﺔﻴﻠﻴﻐﺸﺘﻟﺍ ﺔﺑﻮﻃﺮﻟﺍ(ﻒﺛﺎﻜﺗ ﻥﻭﺪﺑ) ٪٨٠ ﻰﻟﺇ ٣٥ ﺔﻴﺒﺴﻨﻟﺍ ﺔﺑﻮﻃﺮﻟﺍ
ﺩﺎﻌﺑﻷﺍ(ﺔﺻﻮﺑ ١٤,٢ × ﺔﺻﻮﺑ ٣,٩٣ × ﺔﺻﻮﺑ ١٦,٥٤) ﻢﻣ (ﻖﻤﻋ) ٣٦٠,٦ × (ﻉﺎﻔﺗﺭﺍ) ٩٩,٨ × (ﺽﺮﻋ) ٤٢٠
ﺖﻴﺒﺜﺘﻟﺍ ﺔﻘﻳﺮﻃ(ﻱﺭﺎﻴﺘﺧﺍ) MB-25B ﺖﻴﺒﺜﺗ ﺔﻔﻴﺘﻛ ﻊﻣ ﻞﻣﺎﺤﻟﺍ ﻰﻠﻋ ﺖﻴﺒﺜﺘﻟﺍ ،ﺐﺘﻜﻤﻟﺍ ﺢﻄﺳ ﻰﻠﻋ ﺖﻴﺒﺜﺘﻟﺍ
ﻥﺯﻮﻟﺍ(ﻞﻃﺭ ١٣,٤٥) ﻢﺠﻛ ٦,١
ﺐﻴﻄﺸﺘﻟﺍﺖﻳﺎﻣﻮﻟﺃ ،ﺩﻮﺳﺃ ،ﻡﻮﻴﻨﻤﻟﺃ :ﺔﻴﻣﺎﻣﻷﺍ ﺔﺣﻮﻠﻟﺍ
ءﻼﻃ ،ﺩﻮﺳﺃ ،ﺔﻴﻧﺪﻌﻣ
ﺡﺍﻮﻟﺃ :ءﺎﻄﻐﻟﺍ
ﻂﻟﻮﻓ ١ = ﻞﺒﻴﺴﻳﺩ ٠ *
.ﻦﻴﺴﺤﺘﻟﺍ ﻞﺟﺃ ﻦﻣ ﻚﻟﺫﻭ ﺭﺎﻌﺷﺇ ﻥﻭﺩ ﺮﻴﻴﻐﺘﻠﻟ ﺔﺿﺮﻋ ﺕﺎﻔﺻﺍﻮﻤﻟﺍﻭ ﻢﻴﻤﺼﺘﻟﺍ :ﺔﻈﺣﻼﻣ
ﺕﺎﻴﻟﺎﻤﻜﻟﺍ
•
١ ................................................. ﺭﺎﻴﺘﻟﺍ ﺩﺍﺪﻣﺇ ﻚﻠﺳ١ ....................................... ﺔﻴﺑﺮﻌﻟﺍ ﺔﻐﻠﻟﺎﺑ ﻥﺎﻴﺑ ﻖﺼﻠﻣ
