Document Ref 941113-001 Rev 2 Page 4-21
Quantium 310 Maintenance Manual Maintenance Procedures - Hydraulic
29) Feed the motor power cable through the dispenser to the junction box.
30) Fit the sheath onto the motor power cable and feed the cable through the gland into the
junction box. Replace the cable ties and tighten the relevant gland using a 32mm spanner.
Note : ensure that the cable is routed correctly and contained accordingly.
31) Using a small screwdriver, re-connect the motor power cable in the junction box.
Note : refer to the wiring diagrams in section 7.
32) Using a 6mm allen key, re-fit the junction box cover.
33) Ensure that all tools and unused materials are removed.
34) Close the calculator head access door and lock.
35) Re-fit the nozzle panel.
36) Re-fit the hydraulic doors to the dispenser and lock.
37) Re-instate power to the dispenser.
38) Test operation of the new motor and check the direction of the motor rotation is correct.
39) Dispose of all waste accordingly.
