Maintenance Procedures - Electronics Quantium 310 Maintenance Manual
Page 5-12 Document Ref 941113-001 Rev 2
10) Re-fit Comms Board and IEB (where fitted) to the WWC cover assembly as described in
section 5.9.
11) Re-apply W&M seals to the heat sinks on the bottom of the WWC cover.
12) On side A of the calculator head, re-connect ALL cable and connectors to the I/O board
(where applicable).
13) If removed, re-fit I/O cable security cover and secure using the sealing screw.
14) Re-apply W&M seals to the I/O cable security cover (where applicable).
15) Ensure that all tools and unused materials are removed.
16) Close the calculator head doors on both sides of the dispenser and lock.
17) Re-instate power to the dispenser.
18) Test the operation of the new board(s).
19) Dispose of all waste accordingly.
