2-10
(13) “Zoom” button
Enlarges the image of the endothelium. Touching this button shows the magnification adjustment bar. 100%,
200%, 400% can be selected. When the enlarged image is displayed, the image moves so that the tapped
point comes to the center of the frame. Touch the “Zoom” button again to return to the original screen.
(14) "Setup" button
Moves to the Setup screen.
(15) “Method” button
Switches analysis methods.
(16) “Trace Edit” button
Opens the Trace Edit screen.
(17) “Cell Select” button
Opens the cell selection screen.
(18) “Print/Export/Save” buttons
Two buttons can be selected from “Print,” “Export,” and “Save” using the system setup
function. Refer to “3.7.4 Connection & Print” for the setting method.
- Print: Prints the displayed examination data.
- Export: Transfers the examination data to the personal computer.
- Save: Transfers the patient information and examination data to the database.
(19) R/L eyes button
Moves to the R/L eyes analysis screen.
(20) “Dark Area” button
Moves to the dark area analysis screen.
(21) Area (Polymegathism)
Distribution of cells according to their sizes is displayed using a histogram.
(22) Apex (Plemorphism)
Distribution of cells according to their shapes is displayed using a histogram.
