3-49䢢
䕔
[PictBridge settings]
(Fig. 1)
(1) Print Size
Set the printing size.
L / A4 / B5 Form 1 / B5 Form 2
B5 Form 1: When the paper feed tray is centered.
B5 Form 2: When the paper feed tray is left-aligned.
c) PC
Make connection settings to export data to a personal computer with TOMEY
Link or Data Transfer installed.
Touch the “Setting” button (1) of “PC” to open the System Setup screen
related to PC (Fig. 2).
(Fig. 1) (Fig. 2)
(2) Connection permission and selection of cable type
LAN
䠖
Use a LAN cable for connection.
When “LAN” is selected here, all items listed on
this screen need to be set.
USB
䠖
Use a USB cable for connection.
Disable
䠖
Not connected
The initial setting is “Disable.”
(3) Auto Inquiry
T-Link
䠖
The patient information corresponding to the
entered ID is retrieved from TOMEY Link.
Database
䠖
The patient information corresponding to the
entered ID is retrieved from the database in the
SD card of the main unit.
(4) Login
Set the user ID and password to log in to the TOMEY Link. Maximum
number of characters to be entered for the user ID or password is 16.
(5) Host IP address
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(1)
To Next Page
