Assembly step（8）drawing
Assembly step（8）assembly instrucon
1. Fix le buerfly arm(46) on front frame using:
M10*16 hexagon socket buon head bolt(44),Ф10 spring washer(7),Ф10 big washer(35)
2
. Fix right buerfly arm(45) on front frame using:
M10*16 hexagon socket buon head bolt(44) Ф10 spring washer(7), Ф10 big washer(35)
3
. Fix pulley support frame(47) on front frame using:
M12*75 hexagon bolt(29),Ф12 washer(20),Ф12 lock nut(21),reinforcing plate(48)
4
. Fix footplate(49) on seat cushion tube using:
M10*70 hexagon bolt(43),Ф10 washer(5),M10 lock nut(23)
CAUTION: All bolts and pins should be ghtening.
