TOORX MSX3000 - Parts Identification and Diagrams; Detailed Spare Parts List

Spare parts list
3
No. Descripon Note Qty.
1 ground frame 1
2 guide rod Φ25*1853 2
3 back support rod Φ259*1757.5 2
4 hexagon bolt M10*65 6
5 washer Φ10 78
6 hexagon bolt M10*20 8
7 spring washer Φ10 14
8 rubber cushion Φ60*Φ26*42 2
9 counter weight rubber cushion Φ60*Φ26*20 2
10 hexagon socket buon head bolt M8*70 2
11 lock nut M8 6
12 selector rod 92 KG 1
13 counter weight 6 KG 14
14 topmost counter weight 8 KG 1
15 washer Φ8 26
16 weight pin Φ10*100 1
17 lock pin 2
18 pull pin Φ10 2
19 hexagon bolt M12*70 4
20 washer Φ12 23
21 lock nut M12 11
22 front frame 1
23 lock nut M10 32
24 shield support frame 1
25 upper frame 1
26 hexagon bolt M12*130 3
27 right cover 1
28 le cover 1
29 hexagon bolt M12*75 4
30 hexagon bolt M10*25 2
31 axis of rotaon Φ17*57 1
32 seat cushion adjust frame 1
33 seat cushion tube 1
