TOORX MSX3000 - Assembly Step（14

38
Assembly step（14）drawing
Assembly step（14）assembly instrucon
1. Fix seat cushion(76) on seat cushion adjust frame using:
M8*40 hexagon bolt(73),Ф8 spring washer(72),Ф8 washer(15)
2
. Fix back cushion(75) on back cushion adjust frame(74) using:
M8*40 hexagon bolt(73),Ф8 spring washer(72),Ф8 washer(15)
3
. Push back cushion adjust frame(74) fastening into front frame using: pull pin
4. Fix back cushion adjust frame(74) on oblique support using:
M8*25 hexagon bolt(150),
Ф8 spring washer(15)
