TOORX MSX3000 - Assembly Step（15

40
Assembly step（15）drawing
Assembly step（15）assembly instrucon
1. Push sponge tube(81) into back cushion adjust frame,
sponge tube(81) turn into:
sponge inner cap(79),sponge(80),sponge outer cap(78)
screw M8*25 hexagon socket buon head bolt(77)
2
. Push sponge tube(85) into seat cushion adjust frame,
sponge pipe tube(85) turn into:
sponge inner cap(79),sponge(80),sponge outer cap(78)
screw M8*25 hexagon socket buon head bolt(77)
3
. Leg curl elbow tube turn into:
sponge inner cap(79),sponge(80),sponge outer cap(78)
screw M8*25 hexagon socket buon head bolt(77)
