TOORX MSX3000 - Spare Parts List

Spare parts list
4
No. Descripon Note Qty.
34 leg curl elbow tube 1
35 big washer Φ25*10*2.0 6
36 hexagon bolt M8*16 9
37 pull pin Φ12 1
38 sha Φ17*134 1
39 sha Φ17*100 1
40 front push holder 1
41 guard plate 1
42 front push arm 1
43 hexagon bolt M10*70 1
44 hexagon socket buon head bolt M10*16 2
45 right buerfly arm 1
46 le buerfly arm 1
47 pulley support frame 1
48 reinforcing plate 1
49 footplate 1
50 hexagon bolt M10*130 6
51 hexagon bolt M10*115 2
52 hexagon bolt M10*45 19
53 hexagon socket buon head bolt M10*45 1
54 “-” shape pulley frame 2
55 pulley Φ95*26 27
56 connecng sleeve Φ14*100 1
57 pulley spacer Φ22*Φ10.5*45.5 4
58 lat pull cable L:4540mm 1
59 cable hook 1
60 9 link chain & snap hook 5
61 double pulley plate 1
62 middle cable L:1500mm 1
63 hexagon bolt M8*45 4
64 buerfly arm cable L:5375mm 1
65 hexagon bolt M10*75 2
66 hexagon bolt M10*85 1
