TOORX MSX3000 - Assembly Step 15: Sponge Pad Attachment

Assembly step（15）explosion drawing
39
81
80
78
77
79
82
79
79
79
77
78
77
78
80
80
80
80
80
78
78
77
77
78
No. Descripon Note Qty.
77
hexagon socket buon
head bolt
M8*25 6
78 sponge inner cap 6
79 sponge outer cap 6
80 sponge Φ100*175 6
81 sponge tube Φ25*480 1
82 sponge tube Φ25*450 1
