Function Button
10
P/N: 1004636-01
Display Panel
Function Button
Receiver Status LEDs
The status LEDs provide information about the battery life, tracked satellites, memory capacity, and wireless
connectivity. This section describes the color and behavior of each LED.
Tracking Status LED
The tracking status LED displays what type of satellite the receiver is tracking.
Tab le 5.Function Button Features
FUNCTION PRESS BUTTON LED DESCRIPTION
RECEIVER IS OFF
Power Off Press button No action.
RECEIVER IS ON
Start/Stop Data
Logging
1-5 seconds • REC LED is green indicating data logging has started.
• REC LED blinks green each time data is written to the receiver’s
memory.
• REC LED is red when receiver is out of memory, has a hardware
problem, of contains an improper OAF.
Toggle Post-
Processing Mode
Less than 1 second • Press for less than 1 second when “Occupation mode switch”
has been enabled using TRU.
Change Information
Mode
Three times for less
than 3 seconds
• Press three times for less than 3 seconds when “LED blink mode
switch” has been enabled using TRU.
Change Baud Rate of
Serial Port
5-8 seconds • After approximately 5 seconds, the REC LED becomes red.
Release the Function button during the next 3 seconds.
Table 6. Tracked Satellites
Color Description
Green GPS
Yellow GLONASS
Cyan Galileo
Blue SBAS/OMNI
Magenta BeiDou
White QZSS
