Specifications
42
P/N: 1004636-01
Specifications
This chapter provides specifications for the receiver and its internal components.
General Details
Table 7 lists the receiver’s general specifications.
Table 7. General Receiver Specifications
Physical
Enclosure Aluminum, IP67 rated extrusion
Color Topcon Yellow and Topcon Grey
Dimensions (mm) W: 150 mm x H: 60 mm x D: 200 mm
Weight (g) < 2.0 kg (with internal batteries)
Antenna External N connector
Status
display/panel
MINTER (8 LEDs + power button + function button)
Serial/External
Power
Hirose H205-Series (6-pin, multiplex)
• Serial Ports A and B
– RS-232
• Serial Port C
– RS-422
•2x Power
– ODU 5
• Ethernet
– RJ45
•USB Host
– USB Type-A
•USB Device
– Mini-B
USB USB Mini B 2.0 (client)
External antenna
connector
N-Type connector
Bluetooth antenna Fully integrated, high sensitivity
Tracking
Number of
Channels
452 channels Vanguard™ ASIC with patented Universal Tracking Channel Technology
a
Tracked Signals GPS: L1 C/A, L1C, L1P(Y), L2P(Y), L2C. L5
GLONASS: L1 C/A, L1P, L2 C/A, L2P, L3C
GALILEO: GIOVE-A/B, E1b, Galileo E1, E5a, E5b, E6, AltBOC
BDS: B1, B2, B3 with ICD availability
QZSS: L1 C/A, L1C, L2C, L5, LEX
L-Band: 1525-1560 MHz (OmniSTAR and TerraStar)
SBAS: WAAS/EGNOS/MSAS
Multipath
reduction
Yes, code and carrier
PLL/DLL setting Adjustable bandwidth and order
Smoothing
interval
Adjustable, code and carrier
