General Details
43
P/N: 1004636-01
Specifications
Data Output
RTK Corrections
TPS, RTCM SC104 v 2.x, 3.x; CMR/CMR+
b
ASCII Output NMEA 0183 version 2.x and 3.x
Measurement
data rate (max.)
20 Hz standard - Up to 100 Hz optional
c
Data and Memory
Removable media SD card
Internal memory 8 GB standard - Up to 32 GB
Message storage
rate (max.)
20 Hz standard - up to 100 Hz optional
Environment
Operating
temperature
-20°C to +61°C (batteries)
-40°C to +80°C (w/ external power on PW2/charging disabled on PWR1)
-20°C to +50°C (w/ external power on PW1/battery charging)
Storage
temperature
-40°C to +70°C
Humidity 100%, condensing
Waterproof rating IPX7 (1 meter submersion)
Dust rating IP6X (Fully dust proof)
Random vibration MIL-STD 810G, Method 514.6, Broad band noise (random vibration), along each of 3 axes,
Category 4, table 514.6C-IV
Shock MIL-STD 810G, Method 516.5. Table 516.5-I
Alternate Test Method of Classic Pulse; 40g, 11ms duration.
Technology
Topcon Vanguard™ ASIC technology
Fence Antenna™ Technology
Topcon advanced Multipath Rejection (AMR)
Integrity Monitoring (RAIM)
Topcon Automatic File Rotation Mode (AFRM)
Universal Tracking Channels
Power
Internal Batteries 2S x 4P, 7.2v, 1200 mAh
Battery charging
time
<5 hours
Battery charging
method
Connect the AC adaptor to charge the internal batteries. Available run charge when
connected to an external battery. Charging of internal batteries when power input is greater
than 10 V.
External power
input
9 to 28 VDC (operating)
d
28 to 80 VDC (over voltage protection)
Power
consumption
5 W: minimum
8 W: full system tracked (up to 50 W during charging)
Table 7. General Receiver Specifications
