11
4. PRODUCT OUTLINE
& Vertical and Horizontal Jogs
The instrument and telescope can be rotated manually by hand or, for more precise adjustments,
by turning the vertical and horizontal Jogs.
The faster the Jogs are turned, the faster the instrument and telescope rotate.
C"10.1 Auto Pointing Settings" step 3
& Trigger key
When the Trigger key is pressed the instrument carries out the operation indicated by the softkey
in bold type on the screen. This allows the user to continue operation without having to return to
the display to press softkeys.
& Sighting collimator
Use sighting collimator to aim the instrument in the direction of the measurement point.
Turn the instrument until the apex of the triangle in the sighting collimator is aligned with the
target. A circle surrounds the triangle to make it easier to locate.
Wireless antenna
When performing wireless communications, the antenna must be directed towards the zenith.
G
Handle the antenna with care and be aware of the following points when operating.
• An extended antenna may be damaged if struck during operation.
• Do not turn the antenna incorrect direction.
• Always stow the antenna in a downward direction when the instrument is not in use.
