Toro 30605 - InfoCenter Usage and Icons

InfoCenterIconDescription
SERVICEDUE
Indicateswhenscheduledservice
shouldbeperformed
Enginerpm/status—indicatesthe
enginerpm
Hourmeter
Infoicon
Setsthemaximumtractionspeed
Fast
Slow
FanReversal—indicateswhenthe
fanisreversed
Fuellevel
Stationaryregenerationrequired
Airintakeheaterisactive
Raisetheleftdeck
Raisethecenterdeck
Raisetherightdeck
Operatormustsitinseat
ParkingBrakeIndicator—indicates
whentheparkingbrakeison
IdentiestherangeasHigh
Neutral
IdentiestherangeasLow
CoolantT emperature-indicatesthe
enginecoolanttemperatureineither
°Cor°F
Temperature(hot)
TractionorTractionPedal
InfoCenterIconDescription(cont'd.)
Deniedornotallowed
EngineStart
PTO—indicatesthatthePTOison
Stoporshutdown
Engine
Keyswitch
Indicateswhenthemowerdecksare
beinglowered
Indicateswhenthemowerdecksare
beingraised
PINpasscode
Hydraulic-OilTemperature—indicates
thehydraulic-oiltemperature
CANbus
InfoCenter
Badorfailed
Center
Right
Left
Bulb
OutputofTECcontrollerorcontrol
wireinharness
High:over-allowedrange
Low:under-allowedrange
/
Outofrange
Switch
Operatormustreleasetheswitch
