5.Removethehairpincotterandclevispinsfromthe
caster-pivotarms(Figure20).
6.Rotatethetensionrodtoraiseorlowerthepivot
armuntiltheholesarealignedwiththeselected
height-of-cutbracketholesinthemower-deckframe
(Figure20andFigure21).
Figure20
1.Caster-pivotarm3.Clevispinandhairpin
cotter
2.Axle-mountingholes4.Tensionrod
Figure21
7.Inserttheclevispinsandinstallthehairpincotters.
8.Rotatethetensionrodcounterclockwise(ngertight)
toputtensiononadjustment.
9.Removethehairpincottersandclevispinssecuringthe
damperlinkstothemower-deckbrackets(Figure22).
Important:Donotadjustthedamper-linklength.
Thelengthbetweentheholecentersshouldbe
13.7cm(5-3/8inches).
Figure22
1.Damperlink
10.Alignthedamper-linkholeswiththeselected
height-of-cutbracketholesinthemower-deckframe,
inserttheclevispins,andinstallthehairpincotters
(Figure23).
Figure23
